Servo Control Double Glazing Glass Machine Sealing Robot For Insulating Glass
Servo Control Double Glazing Glass Machine Sealing Robot For Insulating Glass
Specifications
Brand Name :
LIJIANG GLASS
Model Number :
LJTJ2540
Certification :
CE
Place of Origin :
JINAN,CHINA
MOQ :
One set
Price :
Negotiable
Packaging Details :
Container
Name :
Insulating glass sealing robot
Max.glass size :
2500*4000mm
Min.glass size :
300*300mm
Glass thickness :
12-56mm
Working speed :
5-40m/min
Air pressure :
0.5-0.7MPa
Description

Servo Control Double Glazing Glass Machine Sealing Robot For Insulating Glass

Parameters :

Max.glass size 2500*4000mm
Min.glass size 300*300mm
Glass thickness 12-56mm
Working speed 5-40m/min
Air pressure 0.5-0.7MPa
Squeeze pressure 32MPa
Voltage power 380V 12kw
Overall dimension 8700*2000*3500mm

Main Features:

  • The glass corners are full without air bubbles, smooth surface, no need to
  • Full automatic and high-efficiency machine
  • Adopt Japan ANCHUAN servo control system with stable performance
  • Adopt timing belt to keep smooth convey with accurate position
  • Adopt 8 servo motors
  • Automatically measure glass size, glue depth and glue speed with linear adjustment
  • Automatically repair glass corners with beautiful surface
  • Smooth convey without scratch and pollution
  • Single function parts are equipped with manual functions, easy adjustment
  • Can coating more than 8 kinds of shaped glass, include Semicircle. Trapezoidal. Parallelogram. Circular. Polygon, etc
  • Seal stepped glass fully at once
  • Spares are produced with high standardization and high precision, ensure the machine can be used with long-term working

Part List:

Name Brand
Servo motor Japan Yaskawa
Servo driver Japan Yaskawa
CPU Japan Yaskawa
Low voltage component Germany Siemens
Guideway Taiwan Hiwin
Switching power supply Taiwan MW
Optoelectronic switch Korea Autonics
Pneumatic component Japan SMC
Touch screen Gaoshan
