Curtain Wall Double Glazing Equipment , Glass Production Line Touch Screen Operating
Curtain Wall Double Glazing Equipment , Glass Production Line Touch Screen Operating
Specifications
Brand Name :
LIJIANG
Model Number :
LJBZ2535
Certification :
CE
Place of Origin :
JINAN
MOQ :
1 SET
Price :
Negotiable
Supply Ability :
1set 30days
Delivery Time :
30days
Packaging Details :
40gp
Max glass size :
2500*4500mm
Min glass size :
300*500mm
Glass thickness :
3-15mm
Insulating glass thickness :
50mm
Glass washing speed :
2-10m/min
Glass conveyor speed :
48m/min
Washing brushes :
3 pairs
Oversea service :
available
Guarantee period :
12 MONTHS
Stepped glass :
available
Triple glass :
available
Shaped Glass :
availabe
Low-e glass :
available
Description

Curtain Wall Double Glazing Equipment , Glass Production Line Touch Screen

LJBZ 2535 Automatic vertical Insulated glazed glass production line uses advanced technology to make high-quality and variety IG automatically, such as double glass, triple glass, shaped glass and stepped glass.

Model Min size of glass(Optional) Max size of glass Low-E Stepped glass Triple glass Gas filling online
LJBZ1825 300*500 1800*2500 Available Available Available Available
LJBZ2025 300*500 2000*2500 Available Available Available Available
LJBZ2230 300*500 2200*3000 Available Available Available Available

LJBZ2535

(Optional)

 300*500 2500*3500 Available Available Available Available

Max.glass size 2500*3500mm/2200*3000mm/2000*2500mm
Min.glass size 280*450mm
Glass thickness 3-15mm
Insulating glass thickness 60mm
Glass washing speed 2-10m/min
Glass conveyor speed 48m/min
Washing brushes 3 pairs
Water supply Water consumption:0.5t/h conductivity:≤50μs/cm
Air supply Flow: 0.8m/min
Air pressure ≥0.8MPa
Total power 3P 380V 50HZ 40KW/27KW/24KW
Dimension 23500*3500*3700mm/18350*2600*3250mm/16400*2500*3100mm
Weight 6500kg/6000kg/5200kg

Main features:

- Self-diagnosis system with touch screen on computer


- Stainless steel washer with 6 brushes, soft brushes from, hard brushes automatically open when Low-E glass input


- Rotate speed of brush frequency control(optional)


- Stainless steel air knife is automatically adjustable according to glass thickness, Max thickness to 19mm


- High speed cleaning ( max 14m/min), Low noise ( max 70dB), high availability working ( 25 second /unit)


- Automatic detection of Low-E glass and alarm for coating in reverse(optional)


- Structure stepped and three-layer I.G. unit available(optional)

Main conditions:

  • Product Name: IG Production Line
  • Keyword: Insulating glass production line
  • Place of orign:Jinan
  • Input Voltage: 380v
  • Max glass size: 2500*3500 mm (Optional)
  • Working Speed: 50m/min
  • Min glass size: 300*500mm
  • Condition: Double glazed glass production line
  • Machine Type: IG machines
  • Production Capacity: 50m/min
  • Place of Origin: Shandong
  • Brand Name: Jinan
  • Model Number: LJBZ
  • Voltage: 380V
  • Certification: CE
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
