Five Axis Insulating Glass Processing Machine For Glass Loading
Five Axis Insulating Glass Processing Machine For Glass Loading
Specifications
Brand Name :
Lijiang
Model Number :
LJJXS-00
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10Set / Day
Delivery Time :
30-40 working days
Packaging Details :
Wooden case ect
Name :
Five-Axis Manipulato for Glass Loading
Power Supply :
380V,50HZ or customized
Total Power :
5.5KW
Max. Glass size :
2000*2500mm
Min. Glass size :
450*280mm
X-axis stroke :
2700mm
Description

Five-Axis Manipulato For Glass Loading Insulating Glass Processing

Five-Axis Manipulator introduction

Performance characteristics of Five-Axis Manipulator

1)Five-Axis Manipulator for Glass Loading is used for glass loading and unloading on insulating glass production line, glass washing machine, edging machine or other glass machines.

2) Adopts five-axis manipulator numerical control system, simple operation, safe and reliable.

3) Five-axis linkage adopts Servo motor with high precision, safety and reliability.

4) The operation is controlled by touch screen, and the graphics are clear and easy to understand.

5) The motion unit is guided by imported linear guide rails.

6) Vacuum system adopts high quality vacuum sucker, high negative pressure, sufficient suction, so the glass won’t fall off.

7) The machine is equipped with automatic alarm for material shortage, under voltage protection, power off protection and other functions, with a high safety factor.

8) Can be customized according to customer requirements.

Five Axis Insulating Glass Processing Machine For Glass Loading

Technical parameters of Glass Loading Machine

Power supply 380V 50HZ
Power 5.5kw
Air source pressure 0.6~0.8Mpa
Max. glass size 2500*2000mm
Min. glass size 450*280mm
X-axis stroke 2700mm
Y-axis stroke 1500mm
Z-axis stroke 1600mm
Dimension 4500*3200*5800mm
