Specifications
Brand Name :
LIJIANG
Model Number :
CP-2500A
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
35000-20000
Supply Ability :
30set
Delivery Time :
30-40
Packaging Details :
Container
Name :
glass washing machine technical parameters CP-2500A
Maximum glass width :
2500mm (effective maximum: 2650mm)
Minimum glass specification :
400mm×400mm (limited to single row on left and right sides)
Glass thickness :
3mm-25mm (digital display)
Speed range :
glass thickness within 3-25mm Vmax=1-12m/min
Main drive, brush speed regulation method :
frequency control
Description

glass washing machine technical parameters CP-2500AWashing machine water tank outside, convenient water tank cleaning

USES:

glass washing machine CP-2500A used for cleaning and drying the upper and lower surfaces

of ordinary plate glass and high quality low-e glass,it is composed of incoming segment,

cleaning air-drying segment and outgoing segment.

2, Structural characteristics:

  • Aluminum alloy assembled structure, no scrap concept, permanent use,

high efficiency, energy saving 70% efficiency;

2. The rest of the sheet metal parts are sprayed with advanced mechanical

paint or powder;

3. The rubber roller is made of vulcanized rubber with stainless steel shaft;

4. The washing part in contact with water is made of stainless steel;

5. Cleaning department, wind staff overall lift, the maximum lift: 350mm,easy to clean and maintain;

6. Three pairs of brush(Ø150mm)Stainless steel shaft configuration (low-e glass, ordinary coated

glass and sunshine coated glass can be washed without damaging the coated surface);

7. Two pairs of special stainless steel aluminum alloy air knife configuration, strong wind, good air

drying effect, with heating system(with temperature control device, optional opening and closing);

8. The fan is equipped with air filter in the air inlet chamber, with large air volume and good air drying

effect,The whole fan box is installed in the upper part of the workshop, with the air filter screen on the

side for easy inspection and cleaning;

9. Main drive for gear transmission, frequency control, digital display , the rotation of the brush roller in

the washing section is driven by independent belts of the upper and lower motors respectively, the

frequency conversion adjustment speed is stable, the service life is long, realizes the cleaning high request

special glass;

Maximum glass width 2500mm (effective maximum: 2650mm)
Minimum glass specification 400mm×400mm (limited to single row on left and right sides)
Glass thickness 3mm-25mm (digital display)
Speed range glass thickness within 3-25mm Vmax=1-12m/min
Main drive, brush speed regulation method frequency control
Table height 900±25mm
Total power 42KW(water-bearing wind heating: 15KW)
Water source self-circulation, tap water (according to civil water standards) and deionized water water supplement (deionized water equipment shall be provided by the buyer)
Power source 380V 50Hz
Dimensions (length × width × height) approximately 6260*4800*3100
Weight 3940kg

Water Tank Outside Cleaning 2500mm Horizontal Glass Washing Machine
