Specifications
Brand Name :
LIJIANG
Model Number :
LJTB01
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
$11000-13000/set
Supply Ability :
6sets/month
Delivery Time :
30days
Packaging Details :
wooden
squeeze pressure :
10-18Mpa
temperature :
110°-140°
spacer width :
6A-27A
speed :
5-47m/min
diameter of butyl cylinder :
200mm
air supply :
0.4m³/min
air pressure :
≥0.6Mpa
total power :
380V,5.7KW,50HZ
dimension :
2800*700*900mm
name :
Butyl Extruder Machine
Warranty :
1 YEAR
Condition :
New
Description

Automatic Butyl Extruder Machine

LJTB01

LJTB 01 Automatic butyl extruder machine is used for spreading aluminum spacer frames evenly with hot melt butyl. The butyl extruder uses largeelectrical control panel which makes the operation more easier than before. The conveyor of aluminum is controlled by frequency converter. The speed can be adjusted from 0m/min to 47m/min, it is the fastest speed in China until now. The butyl extruder is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder adopts vertical rotary support system, making the refill of butyl more easier. The height of squeezing head can be adjusted automatically according to different kinds of aluminum spacers. Finally, the butyl extruder has reached the worldwide technology with the characteristicofcompletefunctions and stable working mode.

Automatic Butyl Extruder Machine，Butyl Extruder Machine，Butyl Machine，Automatic Butyl Machine

Equipment details

Automatic Butyl Extruder Machine，Butyl Extruder Machine，Butyl Machine，Automatic Butyl Machine Automatic Butyl Extruder Machine，Butyl Extruder Machine，Butyl Machine，Automatic Butyl Machine Automatic Butyl Extruder Machine，Butyl Extruder Machine，Butyl Machine，Automatic Butyl Machine

JINAN LIJIANG QUTOMATIC EQUIPMENT CO.LTD is an enterprise which integrated product development, designing, sale and service into a whole. The company is located in the beautiful spring city, Jinan. Because it is close to Beijing-shanghai high-speed railwayline,it’s very convent for transportation.The company adheres to the “Hi-Q products”. We are striving to create thetop-grade products through setting up Tchnology research and development center, inviting some experts to guide. We also cooperate with the domestic well-know enterprises and actively import foreign advanced technology.

Now our company are the main supplier of glass deep processing enterprises in China.Our equipment are used by the main domestic famous glass factories, such as NORTH GLASS, XIN FU XING GLASS,YAO HUA GLASS, DALIAN HUAYING GLASS etc. We also have more than 400 customers who use our machines in China. We have got CE certification in 2017. Sofar our machines has exported to more than 30 countries and regions, just like Europe, South America, Middle East, Southeast Asia and so on.
At the same time, our company cooperates with scientific research institution, which is based on research and development center,imported advanced intelligence. Our company successively cooperates with institution of China North Industries Group and Shandong University in order to develop more new products. Now we have already successfully produced vertical insulating glassproduction line, vertical insulating glass sealing robot and new butyl extruder machine, which quality has reached the domestic top-gradelevel.
LIJIANG GLASS are goes into a leading way in the mechanical field with the advanced technology, first-class products,
perfectservice and good reputation!

Technical Data

Squeeze pressure 10-18MPa
Temperature 110~140℃
Aluminum spacer width 4-30mm
Speed 0-47m/min
Diameter of butyl cylinder 200mm
Air supply 0.4m³/min
Air pressure ≥0.6MPa
Total power 380V, 5KW, 50HZ
Dimension 2600×680×1100mm(L×W×H)
Weight 650kg
