Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Custom Insulating Glass Production Line Double Gas Filiing , Double Filling
Specifications
Brand Name :
LIJIANG GLASS
Model Number :
LJBZ2535
Certification :
CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Supply Ability :
5sets/month
Delivery Time :
30days
Packaging Details :
wooden
Voltage :
3P 380v 50hz
Weight :
6500kg
Color :
The color can be customized
Control system :
Siemens PLC
Min.Glass Size :
450*280mm
Power(W) :
40KW
Dimension(L*W*H) :
23500*3500*3700mm
The optional :
gas filling, double gasfilling,Gas float line
Function :
double gas filling
Model :
LJBZ 2535
Type :
Vertical
Brand :
LIJIANG GLASS
Total Power :
3P 380V 50HZ
Glass Thickness :
3-15mm
Max.Glass Size :
2500mm*3500mm
air pressure :
≥0.8Mpa
insulating Glass Thickness :
50mm
washing brushes :
3 pairs
Description

Automatic Insulating Glass Production Line(double gas filling)

It is the first one in China to use adjustable points to ensure that the platen will never deform.

We adopt CNC technology into the pressing board. We designed the adjustable points inside the pressing board to keep the back plate straight all the time. In China, except LIJIANG, no one can guarantee that the pressing board will remain vertical and straight all the time after used 10 or 20 years. However, we solve this problem already.

Custom Insulating Glass Production Line Double Gas Filiing , Double Filling Custom Insulating Glass Production Line Double Gas Filiing , Double Filling

LIJIANG production line adopts the latest technology, its main purpose is to create high-end quality, to provide customers with the latest production technology, improve production efficiency, save production costs and produce maximum benefits.

It has 6 brushes which are all soft brush, can wash low-e glass, flat glass, tempered glass and so on. It has a diameter of less than 0.1mm bristles, never damage glass, especially for low-e glass.

Custom Insulating Glass Production Line Double Gas Filiing , Double Filling

Customer & Customer collaboration

Custom Insulating Glass Production Line Double Gas Filiing , Double Filling Custom Insulating Glass Production Line Double Gas Filiing , Double Filling

Electrical parameters

NAME ORIGIN BRAND
Transfer motor Germany SIEMENS
Brush motor Germany SIEMENS
Servo motor Germany SIEMENS
PLC Germany SIEMENS
Low voltage electrical appliance Germany SIEMENS
Frequency converter Germany SIEMENS
Micro Switch Taiwan TEND
Button and indicator light France SCHNEIDER
touch screen Taiwan WEINVIEW
Intermediate relay Japan OMRON
Water pump China LINGXIAO
Guide Taiwan HIWIN
Pneumatic Components Taiwan AIRTAC
electric gauge China MIRAN
Photoelectric switch Korea AUTONICS
