Automatic Vertical CNC Insulating Glass Machine Insulated Glass Hollow Glass

Sealing Robot Coating Machine on Sale

Product Application

Insulating glass automatically generates lines can automatically distinguish the coating side of coated glass and low-E glass.

PLC control system with touch screen operation. Outside assembly lines can produce standard double-layer IG and three-layer IG.

Integrated frame design in order to minimize the size of equipment, saving installation space.automatic glue discharging function

to avoid the pipe blockage caused by human factors.

Specification

Main Features

1) Automatically distinguish the coating side of coated glass and low-E glass.

2) PLC control system with touch screen operation.

3) Machine work and fault dynamic display.

4)Outside assembly lines can produce standard double-layer IG and three-layer IG.

5) Production lines are available for both inside and outside panel press, which can produce stepped IG, standard double layer IG and three-layer IG.

6)Insert gas filling in the plate(optional)

7)IG press design-gear and chain synchronous device is driven by hydraulic station.

8)Output:800IG units-single shift 8 hours(double layer IG, size 1M).

9)Two sets of spreading glue systems can work completely independently. One key switch for changing two-component sealant.

10)Coating with glass edge neatly, no dislocation. after coating the glass edge without seam, enrich the corner, quadrilateral smooth surface no need to repair the angle.

Insulating glass sealing robot ig sealing robot machine

l Min & Max glass sizes can be optional

l Adopt 8 servo motors

l Adopt Japan ANCHUAN servo control system with stable performance

l Automatically measure glass size, glue depth and glue speed with linear adjustment

l Adopt timing belt to keep smooth convey with accurate position

l Spares are produced with high standardization and high precision, ensure the machine can be used with long-term working

l The glass corners are full without air bubbles, smooth surface, no need to

l Full automatic and high-efficiency machine

l New scraper design, especially for making train IG with very even sides and corners, without any bubbles.

l Automatically repair glass corners with beautiful surface

l Smooth convey without scratch and pollution

l Single-function parts are equipped with manual functions, easy adjustment

l Shaped IG units (Optional)

l Stepped IG units with four sides (Optional)

l Double and Triple IG units

More Details Pictures
