Automatic Butyl Machine With CE Hot Melt Butyl Extruder Equipment for insulating processing

Aotomatic Bulyl Extruder Machine with high quolity

Application

PLC control system,touch screen interface

Automatically adjust the amount of glue according to different speeds

Automatically identify the width of aluminum bar,accordingly glue nuzzle can adjust automatically.

Hydraulic systerm uses German components to ensurethat the glue is even and full

Fast preheat,improve work efficiency

with preheating function

With exhaust and inflatable function,improve coating quality and asve time for feeding glue

Quickly coating speed,can up to 47m/min

Squeeze pressure:10-18MPa

Temperature:110-140℃

Aluminumspacerwidth:6A-27A

Speed:5-47m/min

Diameter of butyl cylinder:200mm

Air supply:0.4㎡/min

Air pressure:＞0.6Mpa

Total power:380V,5.7KW,50HZ

Dimension:2800*700*900mm

Weight:650kg

Tech parameters of Automatic hot melt Extruder Machine

Equipment details of Automatic Butyl Extruder Insulating Glass machine

Germany Siemens parts

Butyl extruder machine Adopt German brand Siemens PLC, stable performance.

KINCO Touch Screen

Use toubh screen operation ,simple trial,Clear interface, Simple operation, Smart touch screen,Updated programming.

Germany HAVE Valve

High speed butyl extruder machine Adopt Germany’s Harvey valve, more stable performance.

Alarm system

Adopt Automatically alarm system, reminding adding butyl.

Glue cylinder

The rubber cylinder adopt the pull-up structure, which is convenient for changing butyl.

Germany Maximator Cylinder

Super charging system adopts famous pneumatic and hydraulic cylinder, control the pressure of outlet oil strongly.

Adjust the glue putput automatically according to the speed change

The height adjustment of beam is convenient,effective to solve the provlem of white line

Other product of LIJIANG GLASS

Spacer Bending Machine With Aluminum Bars And Warm Bars

Application

The full automatic spacer bending machine is used for making frames ( or other materials) for insulating glass, which replaces the traditional fabrication technology. The Automatic Spacer Bending Machine With Aluminum Bars And Warm Bars can make a variety of convex polygonal aluminum frames by one aluminum strip in one time. The bending machine is available to bend aluminum bars, stainless steel bars, warm bars and thermex and so on. Also on the bending mahcine, also contains printing code , printing label , drilling holes and USB, machine hand for support big frame

Equipment details

• Adopt Siemens PLC control system, touch screen interface
• Japan FUJI CNC servo control system

• Four spacer size storage units
• Aluminum spacers are available in different sizes and sizes

• Automatically cut and feed aluminum spacers
• Bend shaped spacer frames continuously
• Automatically avoid the connecting corner while bending and cutting

• The special machine hand device is used to bend big spacer frame

• Heavy duty connectors is convenience and safety for installation and debugging

• Taiwan Airtac Magnetic valve; German Siemens PLC control system; Japan Fuji servo control system.

• Spare parts of all machine have ID codes.

• Precise bending effect, corner error less than 0.1mm.

Leading Technology

• Spacer printing code function (Optional)

• Automatic drill gas filling hole (Optional)

• Printing label sticker function (Optional)

• USB input function, read the excel format file directly etc (Optional)

• Connect to ERP system (Optional)

• Can bend aluminum spacer ,Technoform, Alupro, Thermix, warm spacer (Swisspacer) and stainless steel ( Optional) and so on.

• We have the special soft system which could avoid the 120mm to reduce waste. For example, if the length of the gusset is 60mm, when the program calculates the right angle, there is a gusset. When you start to bend the rectangular frame, you need firstly transport 120mm, then cut 120mm, and then step on the pedal to bend frame, so you will waste the 120mm.

Technical data

Electrical parameters
