1200V 20A High Surge Silicon Carbide Power Schottky Diode DO-247 Package STPSC20H12WL
1200V 20A High Surge Silicon Carbide Power Schottky Diode DO-247 Package STPSC20H12WL
Specifications
Brand Name :
Original Factory
Model Number :
STPSC20H12WL
Certification :
Lead free / RoHS Compliant
Place of Origin :
CN
MOQ :
10
Price :
Contact for Sample
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
5-8 work days
Packaging Details :
DO-247
Part Number :
STPSC20H12WL
Voltage - DC Reverse (Vr) (Max) :
1200 V
Current - Average Rectified (Io) :
20A
Voltage - Forward (Vf) (Max) @ If :
1.5 V @ 20 A
Reverse Recovery Time (trr) :
0 ns
Operating Temperature :
-40°C ~ 175°C
Description

STPSC20H12WL 1200V 20A High surge Silicon Carbide Power Schottky Diode DO-247 Package

Product Description of STPSC20H12WL

STPSC20H12WL is an ultrahigh performance power Schottky rectifier. It is manufactured using a silicon carbide substrate. The wide band-gap material allows the design of a low VF Schottky diode structure with a 1200 V rating. Due to the Schottky construction, no recovery is shown at turn-off and ringing patterns are negligible. The minimal capacitive turn-off behavior is independent of temperature.

Specification of STPSC20H12WL

Product Status

Active

Voltage - DC Reverse (Vr) (Max)

1200 V

Current - Average Rectified (Io)

20A

Voltage - Forward (Vf) (Max) @ If

1.5 V @ 20 A

Speed

No Recovery Time > 500mA (Io)

Reverse Recovery Time (trr)

0 ns

Current - Reverse Leakage @ Vr

120 µA @ 1200 V

Capacitance @ Vr, F

1650pF @ 0V, 1MHz

Mounting Type

Through Hole

Package / Case

DO-247-2 (Straight Leads)

Supplier Device Package

DO-247

Operating Temperature - Junction

-40°C ~ 175°C

Base Product Number

STPSC20

Features of STPSC20H12WL

No or negligible reverse recovery
Switching behavior independent of temperature
Robust high voltage periphery
Operating from -40 °C to 175 °C
Low VF
ECOPACK®2 compliant

Package outline of STPSC20H12WL

1200V 20A High Surge Silicon Carbide Power Schottky Diode DO-247 Package STPSC20H12WL
