Automobile Chips TPS7A1650QDGNRQ1 LDO Voltage Regulators IC TPS7A1650-Q1 MSOP8

Product Description

TPS7A1650QDGNRQ1 ultralow-power, low-dropout (LDO) voltage regulators offer the benefits of ultralow quiescent current, high input voltage, and miniaturized, high-thermal-performance packaging.
TPS7A1650QDGNRQ1 devices are designed for continuous or sporadic (power backup) batterypowered applications where ultralow quiesc.

Specification Of TPS7A1650QDGNRQ1

Features

• Device Temperature Grade 1: –40°C to 125°C
• Wide Input Voltage Range: 3 V to 60 V
• Ultralow Quiescent Current: 5 µA
• Quiescent Current at Shutdown: 1 µA
• Output Current: 100 mA
• Low Dropout Voltage: 60 mV at 20 mA
• Power-Good With Programable Delay
• Current-Limit and Thermal Shutdown Protections
• Stable With Ceramic Output Capactors: ≥ 2.2 µF
• Package: High-Thermal-Performance MSOP-8

Functional Block Diagram

Applications

• Car Audio, Navigation, Infotainment
• Other Automotive Systems
• Power Supplies for Notebook PCs
• Digital TVs
• Private LAN Systems
