Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters
Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters
Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters
Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters
Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters
Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters
Specifications
Brand Name :
Analog to Digital Converters
Model Number :
ADS1013IDGSR
Place of Origin :
Original
MOQ :
1 pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
35000pcs Per Mouth
Delivery Time :
2-5 work days
Packaging Details :
2500 Pcs/Reel
Certification :
Original Factory
Warranty :
360 Day
Shipping by :
DHL\UPS\Fedex
Unit Weight :
0.000838oz
Subcategory :
Data Converter ICs
Type :
Precision ADC
Features :
Oscillator, Small Size
Input Type :
Differential/Single-Ended
Description

ADS1013IDGSR Integrated Circuit Chip ADC 12bit Sigma Delta VSSOP10 IC Chips

Applications

• Portable Instrumentation

• Battery Voltage and Current Monitoring

• Temperature Measurement Systems

• Consumer Electronics

• Factory Automation and Process Control

Specifications

Product Attribute Attribute Value
Product Category: Analog to Digital Converters - ADC
ADS1013
MSOP-10
12 bit
1 Channel
I2C
3.3 kS/s
2 V to 5.5 V
- 40 C
+ 125 C
Gain Error: 0.25 % FSR
Height: 1.02 mm
INL - Integral Nonlinearity: 0.5 LSB
Input Voltage: +/- 4.096 V
Length: 3 mm
Number of ADC Inputs: 2 Input/1 Input
Number of Converters: 1 Converter
Operating Supply Voltage: 3.3 V
Pd - Power Dissipation: 900 uW
Power Consumption: 0.3 mW
Supply Voltage - Max: 3.3 V
Type: Precision ADC
Width: 3 mm

Description

The ADS1013, ADS1014, and ADS1015 devices (ADS101x) are precision, low-power, 12-bit, I 2Ccompatible, analog-to-digital converters (ADCs) offered in an ultra-small, leadless, X2QFN-10 package, and a VSSOP-10 package. The ADS101x devices incorporate a low-drift voltage reference and an oscillator. The ADS1014 and ADS1015 also incorporate a programmable gain amplifier (PGA) and a digital comparator. These features, along with a wide operating supply range, make the ADS101x well suited for power- and space-constrained, sensor measurement applications.

Analog To Digital Converter Ic ADS1013IDGSR 12bit Analog To Digital Converters

Features

• Ultra-Small X2QFN Package: 2 mm × 1.5 mm × 0.4 mm

• 12-Bit Noise-Free Resolution

• Wide Supply Range: 2.0 V to 5.5 V

• Low Current Consumption: 150 μA (Continuous-Conversion Mode)

• Programmable Data Rate: 128 SPS to 3.3 kSPS

• Single-Cycle Settling

• Internal Low-Drift Voltage Reference

• Internal Oscillator

• I 2C Interface: Four Pin-Selectable Addresses

• Four Single-Ended or Two Differential Inputs (ADS1015)

• Programmable Comparator (ADS1014 and ADS1015)

• Operating Temperature Range: –40°C to +125°C

Trading Guides

Shipping Delivery period

For in-stock parts, orders are estimated to ship out in 3 days.
Once shipped, estimated delivery time depends on the below carriers you chose:
DHL Express, 3-7 business days.
DHL eCommerce,12-22 business days.
FedEx International Priority, 3-7 business days
EMS, 10-15 business days.
Registered Air Mail, 15-30 business days.
Shipping rates

After confirming the order, we will evaluate the shipping cost based on the weight of the goods
Shipping option

We provide DHL, FedEx, EMS, SF Express, and Registered Air Mail international shipping.
Shipping tracking

We will notify you by email with tracking number once order is shipped.

Returning

warranty

 Returning

Returns are normally accepted when completed within 30 days from date of shipment.Parts should be unused and in original packaging.Customer has to take charge for the shipping.
Warranty

All Retechip purchases come with a 30-day money-back return policy, This warranty shall not apply to any item where defects have been caused by improper customer assembly, failure by customer to follow instructions, product modification, negligent or improper operation
Ordering

Payment

T/T,PayPal, Credit Card includes Visa, Master, American Express.
