Insulated Gate Bipolar Transistor FGH40N60SFD
Insulated Gate Bipolar Transistor FGH40N60SFD
Insulated Gate Bipolar Transistor FGH40N60SFD
Insulated Gate Bipolar Transistor FGH40N60SFD
Insulated Gate Bipolar Transistor FGH40N60SFD
Insulated Gate Bipolar Transistor FGH40N60SFD
Specifications
Brand Name :
ON
Model Number :
FGH40N60SFD
Place of Origin :
Original
MOQ :
10 pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
3000 pcs Per Day
Delivery Time :
1-3 work days
Packaging Details :
600 Pcs/box
Type :
600V 40A IGBT Transistors
Description :
IGBT Transistors 600V 40A 378W
Package :
TO-247
Packaging :
Tube&Box
Shipping by :
DHL\UPS\Fedex\EMS\HK Post\TNT
Lead time :
2-3 Working days
Description

FGH40N60SFD FGH60N60SFDTU FGH40N120ANTU FGH40N65UFDTU Insulated Gate Bipolar Transistor

Applications

• Automotive Chargers, Converters, High Voltage Auxiliaries

• Inverters, PFC, UPS

Specifications

Product Attribute Attribute Value
Product Category: IGBT Transistors
Si
TO-247
Through Hole
600 V
2.3 V
- 20 V, + 20 V
80 A
290 W
- 55 C
+ 150 C
Tube
Continuous Collector Current Ic Max: 80 A
Height: 20.82 mm
Length: 15.87 mm
Width: 4.82 mm
Unit Weight: 0.225401 oz

Description

Using Novel Field Stop IGBT Technology, ON Semiconductor’s new series of Field Stop IGBTs offer the optimum performance for Automotive Chargers, Inverter, and other applications where low conduction and switching losses are essential.

Insulated Gate Bipolar Transistor FGH40N60SFD

Features

• High Current Capability

• Low Saturation Voltage: VCE(sat) = 2.3 V @ IC = 40 A

• High Input Impedance

• Fast Switching

• Qualified to Automotive Requirements of AEC−Q101 (FGH40N60SFDTU−F085)

• These Devices are Pb−Free and are RoHS Compliant
