T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
Specifications
Brand Name :
TE Connectivity
Model Number :
T9SV1K15-12
Place of Origin :
Original Factory
MOQ :
5pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5000pcs Per Mouth
Delivery Time :
3-5work days
Packaging Details :
50 Pcs
Product Category :
General Purpose Relays
Description :
12V 35A 1 Form A SPST NO Solder Pin
Certification :
Original Factory Pack
Mounting Style :
Through Hole
Shipping by :
DHL\UPS\Fedex\EMS\HK Post\TNT
Unit Weight :
1 oz
Part Aliases :
2027395-1
Description

T9SV1K15-12 12VDC 35A 1 Form A SPST Power PCB Relay T9S Solder Pin General Purpose Relay

> Typical applications

Photovoltaic inverter

Electrical vehicle loading stations

Electrical vehicle

> Features

• 1 pole 35A, 1 form A (NO) contact

• Contact gap >1.5/1.8/2.1 mm options available

• 350mW hold power1) n Ambient temperature up to 85°C at 35A

• Meet VDE 0126-1-1 and IEC 62109-2

• Product in accordance to IEC 60335-1

• EN61095: AC7a at 85°C

T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay

> Safety Approval

VDE 40030974, UL E58304, TUV R50369970

> Coil Data

Rated coil voltage 12VDC

Coil insulation system according UL class F

> Specifications

Product Attribute Attribute Value
Product Category: General Purpose Relays
Power Relays
Standard
12 VDC
1 Form A (SPST-NO)
35 A
Solder Pin
Through Hole
277 VAC, 30 VDC
Non-Latching
64 Ohms
188 mA
Silver Nickel (AgNi)
32.5 mm
27.4 mm
20.4 mm
Contact Form: SPST (1 Form A)
