W25Q80DVSNIG NOR Flash Memory 8Mbit 104 MHz 2.7V to 3.6V SPI Flash SOIC-8

Specifications

Description

The W25Q80DV supports the standard Serial Peripheral Interface (SPI), and a high performance Dual/Quad output as well as Dual/Quad I/O SPI: Serial Clock, Chip Select, Serial Data I/O0 (DI), I/O1 (DO), I/O2 (/WP), and I/O3 (/HOLD). SPI clock frequencies of up to 104MHz are supported allowing equivalent clock rates of 208MHz (104MHz x 2) for Dual I/O and 416MHz (104MHz x 4) for Quad I/O when using the Fast Read Dual/Quad I/O instructions. These transfer rates can outperform standard Asynchronous 8 and 16-bit Parallel Flash memories. A Hold pin, Write Protect pin and programmable write protection, with top, bottom or complement array control, provide further control flexibility. Additionally, the device supports JEDEC standard manufacturer and device identification with a 64-bit Unique Serial Number.

Pin Configuration SOIC 150-MIL/208-mil AND VSOP 150-mil:

Figure 1a.Pin Assignments, 8-pin SOIC 150-MIL(Package Code SN) & 208-MIL(Package Code SS) & VSOP 150-mil (Package Code SV)

Features

• Family of SpiFlash Memories

– W25Q80DV/DL: 8M-bit/1M-byte (1,048,576)

– 256-byte per programmable page

– Standard SPI: CLK,/CS,DI,DO,/WP,/Hold

– Dual SPI: CLK, /CS, IO0, IO1, /WP, /Hold

– Quad SPI: CLK, /CS, IO0, IO1, IO2, IO3

– Uniform 4KB Sectors, 32KB & 64KB Blocks

• Highest Performance Serial Flash

– W25Q80DV

104MHz Dual/Quad SPI clocks

208/416MHz equivalent Dual/Quad SPI

50MB/S continuous data transfer rate

– W25Q80DL

80MHz Dual/Quad SPI clocks

160/320MHz equivalent Dual/Quad SPI

40MB/S continuous data transfer rate

• Low Power, Wide Temperature Range

– W25Q80DV: Single 2.7 to 3.6V supply

– W25Q80DL: Single 2.3 to 3.6V supply

– <1µA Power-down(typ.)
