49inch 4K/8K UHD ADS VIDEO WALL
49-Inch Commercial-Grade 4K Display Panel
BOE’s World’s First 49 Inch 2×2 True 4K Splicing Solution

The 49-Inch Single Screen Has A 4K Ultra-High Resolution Of 3840×2160, Which Is 4 Times The Ordinary Full HD Resolution. It Is Equipped With BOE
The Unique Color Optimization Function Makes The Performance Of Color And Black Purity Sharper, And The Picture More Delicate And Vivid.



The 49-Inch 2×2 Splicing Solution Can Achieve The Industry’s Highest 4K Point-To-Point Resolution Of 49 Inches, 7680×4320, And Can Be Adapted To High-End Displays In Various Governments, Agencies, Shopping Malls, Hotels, Conference Rooms, Stations, Airports, Schools And Other Places.
Need.
In Terms Of Overall Resolution, It Is 16 Times The Resolution Of Ordinary FHD Displays. In Terms Of Size, It Is 150 Inches Long.
3.31m, Height 1.88m, Equivalent To The 3×3 Size Of An Ordinary 49-Inch FHD Splicing Screen, In The Same Size
There Are Fewer Seams, Higher Resolution, And Clearer Images.


4k/8K Display, Larger And Clearer

The Overall 2×2 4K,8K Display Solution Has Rich Details Even If The Image Is Zoomed In At Close Range, Showing Perfect Image Quality.
And The Height Is 20% Higher Than That Of A Normal Adult Man.

Ultra-Thin Bezel Design
Built-In Splicing Function

Based On The Excellent Performance Of The 4K/8K UHD Display Panel, Unique LED Backlight Technology Is Added, And The Ultra-Thin Frame Design Maximizes The Display Area, Higher Image Integrity, Wider Viewing Range, And More Perfect Visual Presentation. Stable Metal Shell Design, Sturdy And Easy To Install, Suitable For Various Purposes, Saving Installation Costs And Manpower. Suitable For Shopping Malls, Restaurants, Department Stores, Office Buildings, Conference Rooms, Stations, Airports, Schools And Other Commercial Places, Providing Commercial Services, Etc.
Level Splicing Solution.



49” 4K/8K UHD ADS VIDEO WALL
Vision Beyond Imagination
Perfect Color And Contrast Consistency From Any Angle

Commercial Grade, Efficient And Stable
BOE Provides Industry-Leading Display Energy Efficiency And Technology, Using Self-Developed ADS Panel Technology To Make Timely Changes
The Arrangement Of Liquid Crystal Molecular Particles Enables The Screen To Respond Faster, More Stably, And Operate Efficiently And Stably, Meeting The Needs Of
Customer Professional Display Needs.

ADS/VA Touch Screen Comparison

Built-In Splicing Function
Through The Display Of The Splicing Screen And The Built-In Embedded Screen ID, A Diverse And Shocking Impact Presentation Is Created.

Ultra-Thin Bezel Design
3.5mm Bezel To Bezel, 2x2 Splicing Creates The Ultimate Perfect Vision With Zero Seams.


Ultra-Wide Viewing Angle, Bright And Natural Colors
Unique Excellent Color Inversion And Brightness Conversion Performance, 178° Viewing Angle, Viewing Products From The Front And At Different Angles
Raw Color Changes Cannot Be Discerned With The Naked Eye. The Colors Are Bright And Saturated At Any Angle, And The Image Quality Is Natural, Stable, And Perfectly Consistent.

ADS Hard Screen/VA Effect Comparison

Local Dimming Function For Ultra-High Contrast
Each 49-Inch Splicing Screen Is Equipped With Local Dimming Technology Independently Developed By BOE. The Whole Machine Can Dynamically Adjust The Brightness Of The Backlight According To The Content Displayed On The Screen, Thus Completely Solving The Light Leakage Characteristics Of The LCD Screen And Achieving Ultra-High Contrast And Display.
More Details Appear On The Screen.


Turn Off The Local Dimming Function. Turn On The Local Dimming Function To Display More Details On The Screen.

Backlight Mixing Technology Improves Overall Uniformity
LED Is Currently The Main Light Source Material For LCD Backlights. Due To The Limitations Of The LED Manufacturing Process, There Will Be Some Differences In The Optical Data Of The LEDs Produced. In This Case, LEDs Made Into LCD Backlights Will Make The Overall Picture Uniform When Used In Splicing.
Decreases, Resulting In Color Difference. BOE Splicing Screen Starts With LED, Which Has The Greatest Impact On Color Difference, And Adopts Independently Developed And Unique
LED Backlight Hybrid Technology Ensures That The Impact Of Color Aberration On The Overall Picture Is Eliminated To The Greatest Extent.


Using Our Company's Unique LED Backlight Hybrid Technology To Improve The Overall Color Consistency Of The Picture

Moving Images Are Better
The Dynamic Image Presentation Is More Streamlined, Delicate And Clear, Solving The Problems Of Image Afterimage And Jitter On Traditional Display Screens, And Is More Suitable For
For Advertising Screens That Require Ultra-High Image Quality, It Is More In Line With The Needs For Fast Motion Screen Presentation.



Schematic Diagram Of 150” 2X2 Splicing Solution

Product Interface Diagram

Product Structure
