Specifications
Brand Name :
MTHGH
Model Number :
IBOX-601
Place of Origin :
China
Certification :
CE/CCC/FCC Class A/ROHS
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 Set
Delivery Time :
7-10 work days
Packaging Details :
Standard carton package : carton+ plastic bag+ foam+ honeycomb paperboard+ pack thread.
Type :
Industrial Computer
Com Port :
Support RS232/RS422/RS485
Expansion Slots :
Mini PCIe, MSATA
Temp :
-20℃～60℃
Serial Ports :
4 *COM
Processor :
Intel Core I5-7200U OR I3-6100U/I7-6500U
HDMI :
X*1
VGA :
X*1
Application :
For Entry Exit Terminal
Description

Industrial Mini PC IBOX-601 Plus

Intel the 6th or 7th Core™ i3/i5/i7 Processor

Fanless Industrial PC

Features:

◇ All aluminum structure,fanless design；
◇ Onboard Intel 6th or 7th Generation Core i3/i5/i7；
◇ Support 1*DDR4 Slot,Max. Support 16G；
◇ Support 1*MSATA Slot,1*2.5” HDD；
◇ Support 6*COM(2*RS232/485 Optional)
◇ Support DC 9～19V wide voltage Input(DC 9～36V Optional)
◇ Support OS:
Fanless Industrial Fanless Mini PC With Intel Core I5-7200U ProcessorFanless Industrial Fanless Mini PC With Intel Core I5-7200U ProcessorFanless Industrial Fanless Mini PC With Intel Core I5-7200U ProcessorFanless Industrial Fanless Mini PC With Intel Core I5-7200U Processor

Specification:

Model IBOX-601 Plus
Color Black(Color can be customized)
Material High-quality all aluminum,surface anodic oxidation
Processor Onboard Intel Core i3 6100U(Dual core quad threading,2.3GHz,TDP: 15W)
Onboard Intel Core i5 7200U(Dual core quad threading,2.5GHz,Max turbo 3.1GHz)
Onboard Intel Core i7 6500U(Dual core quad threading,2.5GHz,Max turbo 3.1GHz)
CPU Architecture Skylake-U / KabyLake-U
RAM Support 1*DDR4 1866/2133 SODIMM RAM Slot,Max. Support 16GB
BIOS AMI EFI BIOS
Display Chip Integrated Intel HD Graphics 520/620
Display Port 1*VGA,1*HDMI
Front I/O 4*USB2.0,2*COM,1*Power Switch
Rear I/O 4*USB3.0,4*COM(COM4,COM5 RS232/485 Optional),2*Intel 1000M LAN
1*VGA,1*HDMI,1*DC Input,1*3PIN Power Supply Phoenix Connector
1*Mic,1*Line Out
Expansion Slot Support 1*MINI PCIE Slot(Support MSATA)；
Support 1*MINI PCIE Slot(WIFI/3G/4G Choose one from three),Embedded SIM Slot；
Optional Ports:GPIO,PS/2(Standard version doesn’t include these ports)
Network 2*Intel i211-AT 10/100/1000M LAN
Storage Support 1*MSATA Slot,1*2.5” HDD
Input Voltage Support DC 9～19V Input(DC 9～36V Optional)
Other Function Auto power on when there is electricity,Timing boot,Wake on LAN,PXE boot,Watchdog(0～255 level)(Standard version doesn’t set these function)
Work Temp 0℃ ～ +50℃(Commercial HDD),-20℃ ～ +60℃(Industrial SSD),Surface air flow
Work Humidity 5% ～ 95% non-condensing
Certificates CE, CCC, FCC Class A, ROHS
Dimension 230 * 166 * 68 mm【Not include bracket】
Net Weight 3.0 kg【Not include bracket】
Application Industrial automation, medical, logistics transportation, warehouse, electronic education etc.

IBOX-601 Plus Drawing:

Fanless Industrial Fanless Mini PC With Intel Core I5-7200U Processor

Fanless Industrial Fanless Mini PC With Intel Core I5-7200U Processor

Fanless Industrial Fanless Mini PC With Intel Core I5-7200U Processor

Accessories List
Name Quantity Specification
Power Adapter 1 12V 5A
Power Cord 1

Any Plug Optional

(China, US, EU, UK etc.)
Bracket 2 Standard
CD Driver 1 Neutral

Order Information
Configuration 1 IBOX-601 Plus(i3) Intel Core i3 6100U Standard Port
Configuration 2 Intel Core i3 6100U Support 2*RS485
Configuration 3 IBOX-601 Plus(i5) Intel Core i5 7200U Standard Port
Configuration 4 Intel Core i5 7200U Support 2*RS485
Configuration 5 IBOX-601 Plus(i7) Intel Core i7 6500U Standard Port
Configuration 6 Intel Core i7 6500U Support 2*RS485
