32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D
32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D
32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D
32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D
Specifications
Brand Name :
Master Touch
Model Number :
MST-TPS-32-ETI
Place of Origin :
Suzhou, Jiangsu, China
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000~100000 pieces/Month
Delivery Time :
5-8 days
Packaging Details :
carton
Controller IC :
EETI
O.S. :
Windows/ Android/ Linux
Touch Points :
10
Touch Technology :
Pcap(projected capacitive)
USB Cable Length :
1m
Screen Size :
32''
Sensor Glass :
1.1mm
Cover lens O.D :
762.6(L)×457(W)mm
Description

32 Inch Surface Tempered glass Touch Panel Structure 762.6×457 Cover Lens O.D

1. Product Description

Master Touch Touch Panel with Structure is to glue the structural parts whose size is the same as the TP's outline dimension and the TP with silicone or two-component glue, so that the two are firmly bonded together. Doing so can increase the overall strength and thus protect the TP to a certain extent.

This TPS product uses G + G Capacitive Touch Panel, which is made of a surface tempered glass and a ensor glass with Pcap technology. P-cap Technology is based upon the constant monitoring of the electrical capacity of the touch area that is changed by a human finger. As the human body is an electrical conductor, touching the surface of the screen results in a distortion of the screen’s electrostatic field. Depending on the location of the touch and the movement that is detected by the capacitive touch sensor (swiping, tapping), a specific action will be triggered.

2. Genaral Specification

2.1 Basic Features

Item Feature Remarks
Controller EETI3103-01
Channel TX: - RX:- -
Power 5V USB: 4.7V ~ 6.0V, Typical:5V
Communication USB USB: 2.0 Full Speed
Touch points 10 -
O.S. Windows/ Android/ Linux plug and play
Power Consumption

1.Active Mode: Max.120mA @ USB Input 5V

2.Idle Mode: 90mA @ USB Input 5V

3.Sleep Mode: less than 1mA @ USB Input 5V

2.2 Mechanical Features

Item Specification Unit
Screen Size 32 Inch
Viewing Area 760.6(L)×394.1(W) mm
Cover lens O.D 762.6(L)×457(W) mm
2.3 Optical Spec.
Item

Content
V.A. Transparency

≧85%

3. Sensor Spec.

Item Thickness Unit
Stacked structure Cover 4.0 mm
SCA 0.25
ITO 1.1
Sensor Glass
ITO
Sensor Dimension OD Size X 718.3
Y 416.3

4. Electrical Spec.

Item Type Value Unit Remarks
Operating Temperature - -20 ~ +80 ℃

Humidity

20%~85% RH
Storage Temperature - -30 ~ +80 ℃

Humidity

20%~85% RH
ESD Requirement ESD air requirement ±8 KV Air
ESD contact requirement ±6 KV Touch

5. Test

Item Specification Result
Cover lens Ball Drop 200g ± 2g
35cm

One drop test on each of the 5 selected points, No damage
Hardness Pencil: 6H
Pressure: 1N/45°		 Hardness ≧ 6H
Warpage By Gauge Warpage 0.1% ≦ Length *
FPC/COF Bending Bending range0-180° 30times
Electrical Function ok		 -

6. Drawing

32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D

7. Details

32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D

8. FAQ

32 Inch Surface Tempered Glass Touch Panel Structure 762.6x457 Cover Lens O.D
