JRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracy
JRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracy
Specifications
Brand Name :
JRC
Model Number :
JLN-550
Certification :
CCS
Place of Origin :
japan
Payment Terms :
L/C, T/T
Delivery Time :
15 Days
MOQ :
one set
Supply Ability :
30 set per month
Packaging Details :
carton box
Operating system :
2- axis 4-beam pulse Doppler sonar or ROT-combined 3-axis 4-beam pulse Doppler sonar (ROT:option
Operating frequencies :
240kHz (BT : for speed against the ground) 2MHz (WT : for speed against the water)
Distance run range :
0 to 99999.99nm
Depth range :
BT : 2 to 250m (below hull bottom)depending upon sea bottom conditions WT : 3m or more (below hull bottom)
Speed measuring accuracy :
±1% or 0.1 kts whichever is greater
Total distance run accuracy :
±1% or 0.1 nm whichever is greater
Power consumption :
300VA or less
Operating temperature :
-15deg.C to +55deg.C
Description

JRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracy

JRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracyJRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracyJRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracyJRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracy

JRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracy

The JLN-205 Doppler Log is designed as a device of ship speed measurement and information. The JLN-205 utilizing high frequency of ultrasonic wave brings high stability and accuracy of speed measurement.
In addition, a miniaturized transducer will enable to install on the bow where is in less influence against tiny bubbles.

Outline

Stable & high accurate measurement
Easy reading of speed indication

JRC JLN 550 4 Beam Pulse Doppler Sonar Marine 2 Axis Speed Log Low Power Consumption High Speed measuring accuracy

  • Ensuring accurate measuring and stable indicating of ship speed since measurement is insensible to bubbles generated in navigation.
  • The installation on bow of what is less bubbles influence will be accomplished with a miniaturized transducer.
  • The large characters in main display helps easy glance.
  • To enable connecting GPS receiver will bring comprehensive speed information calculated by GPS information.
  • Various option units can help to configure an optimal Doppler Log system.
  • This equipment is complied with the following standards.
  • IMO Resolution A.824(19),Revised IMO Resolution MSC.96(72),IMO Resolution A.694(17).
  • IEC60945:2002,IEC61162-1:2000
