RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting
RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting
Specifications
Brand Name :
THUNDSEA
Model Number :
PTK- 20 Inertial Measuring System for Pipeline Surveying
Certification :
CCS
Place of Origin :
Qingdao
MOQ :
one set
Payment Terms :
L/C, T/T
Supply Ability :
30 set per month
Delivery Time :
15 Days
Packaging Details :
carton box
Attitude :
0.05deg,1σ
Heading :
0.5deg,1σ
Storage :
≥32G
Accuracy :
1.8m~3.6m over 1km~2km aiding
Veiocity :
±400deg/s
Acceleration :
±20g
Vibration :
0.04g²/hz@20~2000hz
Shock :
30g@6ms,keep accuracy;50g@11ms,survival
Size :
φ80×190mm
Power supply :
24V DC
Weight :
≤2.5kg
Power Consumption :
≤15W
Interface :
RS232,USB
Description

RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting

Overeview

Based on Inertial Navigation Technology and FOG technology, PTK-20 consists of three fiber optic gyroscopes, three flexible accelerometers and electronic devices for signal

processing. The gyroscopes are used to determine the attitude and heading and accelerometers are used to determine translational motion.

PTK-20 contains fiber optical gyroscopes (0.003-0.5 degree/h). Different precision optical gyroscopes can be chosen according to different applications. We can customize

different accuracy and size on basis of customers‘ requirements.

The pipelines must be checked regularly for maintenance purpose with help of effective inspection tools searching for damage such as deformation, corrosion or leaks. With the help of our PTK-20 Inertial Measuring system, it is easy and precise to determine the exact location of the inspection tools. Attribute to its high accuracy, the scope of necessary repairs has been largely reduced, resulting in much

less repair costs.

Technical Data

Performance

Alignment

5min

Attitude

0.05deg,1σ

Heading

0.5deg,1σ

Storage

Storage

≥32G

Reading Speed

USB2.0,rate≥35Mb/s

Accuracy

1.8m~3.6m over 1km~2km aiding

Measuring Range

Veiocity

±400deg/s

Acceleration

±20g

Environment

Working TEMP

﹣40℃~70℃

Storage TEMP

﹣55℃~85℃

Vibration

0.04g²/hz@20~2000hz

Shock

30g@6ms,keep accuracy;50g@11ms,survival

SWaP

Size

φ80×190mm

Power supply

24V DC

Weight

≤2.5kg

Power Consumption

≤15W

Interface

RS232,USB

.

RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting
