HANFONG 12v 24v Mppt Solar Charge Controller 10a to 100 A Solar Battery Charger Controller Solar power system guangzhou
HANFONG 12v 24v Mppt Solar Charge Controller 10a to 100 A Solar Battery Charger Controller Solar power system guangzhou
Specifications
Brand Name :
Hanfong
Model Number :
SMP-10
Certification :
CE ISO ROSH
Place of Origin :
China
MOQ :
90pcs
Price :
$27.8/pcs
Payment Terms :
T/T
Supply Ability :
1000pcs/week
Delivery Time :
15 days
Packaging Details :
Box size：173.6*117.1*48.2mm Packing size：：35*29.5*24.5CM 30pcs/carton
Range :
15V to 75V
Battery Vol :
12 / 24 V Auto Select
Max Battery :
10A
Max PV :
75v
Peak efficiency :
98%
Self consumption :
Less than 10mA
Charge algorithm :
Multi-stage adaptive
Color :
Bule
Description

E-mail us for more information about

MPPT CONTROLLER

Blue Boby 12v / 24v 10A MPPT Solar Charge Controller For Solar Energy Systems Sun Light Monitor

MPPT Solar Controller Introduction

HANFONG 12v 24v Mppt Solar Charge Controller 10a to 100 A Solar Battery Charger Controller Solar power system guangzhou

SMP-10 series solar controller is an advanced MPPT controller than PWM controller to improve the charging efficiency over 30%~60%, which has the automatic identification system, PV wide input voltage range, can charge the battery discharge, the intelligent control mode. The maximum power point SMP series controller built-in sensitive tracking algorithm to quickly and accurately find the maximum in order to obtain the power point of the photovoltaic battery photovoltaic energy, more to improve the efficiency, reduce the cost of the system, is suitable for the amorphous silicon.

Features:

●Ultra fast Maximum Power Point Tracking (MPPT)

●Advanced Maximum Power Point Detection in case of partial shading conditions

●Extensive electronic protection

●Internal temperature sensor

●Adaptive three step charging

●Auto battery voltage recognition

●Flexible charge algorithms

●PV reverse polarity protection

●PV reverse current protection

Applications:

Solar system.

Specifications:

Model SMP 10A SMP 15A SMP 20A
Battery voltage 12/24 V Auto Select 12/24 V Auto Select 12/24 V Auto Select
Maximum battery current 10A 15A 20A
Maximum PV power,12V 1a,b) 150W (MPPT range 15V to 75V) 175W (MPPT range 15V to 75V) 300W (MPPT range 15V to 75V)
Maximum PV power,24V 1a,b) 300W (MPPT range 15V to 75V) 350W (MPPT range 15V to 75V) 600W (MPPT range 15V to 75V)
Maximum PV open circuit voltage 75V
Peak efficiency 98%
Self consumption Less than 10mA
Charge voltage 'absorption' Default setting 14.4V/28.8V


​
