90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control
90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control
90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control
90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control
Specifications
Brand Name :
CHIFON
Model Number :
FPR500A-90G/110P-T4
Certification :
CE,ISO,SGS,EAC
Place of Origin :
CHINA
MOQ :
1pcs
Payment Terms :
L/C, T/T, Paypal
Supply Ability :
10000pcs per month
Delivery Time :
sample order 2 working days, bulk order 7-10 working days
Packaging Details :
Wooden case 600*420*355mm
Motor Power :
90kw/120HP
Model :
FPR500A-90G/110P-T4
Frequency :
50/60Hz
Motor Phase :
Three phase
Input Voltage :
380-460v
Output Voltage :
380-460v
Warranty time :
18months
Certificate :
CE,ISO
PID control :
Built-in PID Control
Control Mode :
V/F control
Description

Delta Equivalent VFD Inverter 50Hz 60Hz 380V 3 Phase to 380V 3 Phase Converter


90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control



Technical characteristics

Drive motor type:Ac asynchronous motor, Ac permanent magnet synchronous motor

Four control modes:PG vector control(FVC), PG- free vector control(SVC),

V / F control, Torque control

Speed control range:PG vector control(FVC)1:1000

PG- free vector control(SVC)1:200

V / F control 1:50

Speed control accuracy:PG vector control (FVC)±0.2%

PG- free vector control (SVC)±0.5%

Starting torque:PG vector control(FVC):180 % rated torque/0.01Hz

PG- free vector control (SVC)150% rated torque/0.25Hz

Torque control accuracy:PG vector control (FVC)±5%

PG- free vector control (SVC)±8%

Multi - motor switching: Two groups of motor parameters can realize the switching control of the two motors.

Motor overheating protection:Optional IO expansion card, analog A / 3 can accept input from motor temperature sensor

Supports multiple encoders:Supports differential, open collector, uvw, rotary transformer, sine and cosine encoder

Torque limitation and control: the "excavator" feature, automatically limits the torque during operation to prevent frequent overcurrent trips. Closed loop mode can realize torque control.

Product packaging details:

VFD Model

carton size

(L*W*H)mm

 Net weight Gross weight
Mini size FPR500M-0.75G-T4 22*14*19 0.95kg 1.3kg
FPR500M-1.5G-T4
FPR500M-2.2G-T4
FPR500M-4.0G-T4 24*18*21 1.6kg 2.0kg
FPR500M-11G-T4 32.5*25*26 3.45kg 4.15kg
FPR500M-22G/30P-T4 39.5*29.5*28.5 6.6kg 7.65kg
S size FPR500A-0.75G-S2 24*18*21 1.6kg 2.0kg
FPR500A-1.5G-S2
FPR500A-2.2G-S2
FPR500A-0.75G-T4
FPR500A-1.5G-T4
FPR500A-2.2G-T4
M size FPR500A-4.0G/5.5P-T4 32.5*25*26 3.1kg 3.85kg
FPR500A-5.5G/7.5P-T4
FPR500A-7.5G/11P-T4
L size FPR500A-11G/15P-T4 39.5*29.5*28.5 6.6kg 7.65kg
FPR500A-15G/18.5P-T4
FPR500A-18.5G/22P-T4
Iron case FPR500A-22G/30P-T4 52.5*35*32 18.55kg 18.9kg
FPR500A-30G/37P-T4
FPR500A-37G/45P-T4
FPR500A-45G/55P-T4 600*420*355 kg 36.25kg
FPR500A-55G/75P-T4
FPR500A-75G/90P-T4 700*475*400 kg 51.9kg
FPR500A-90G/110P-T4
FPR500A-110G/132P-T4
FPR500A-132G/160P-T4 800*600*425 kg 85kg
FPR500A-160G/185P-T4
FPR500A-185G/200P-T4
FPR500A-200G/220P-T4
FPR500A-220G/250P-T4 1400*850*500
FPR500A-250G/280P-T4
FPR500A-280G/315P-T4
FPR500A-315G/355P-T4

FAQ:

1. What voltage range can you support?

Single-phase 220v input, single-phase 220v output;

Single-phase 220v input, three-phase 220v output;

Three-phase 220v input, three-phase 220v output;

Single-phase 220v input, three-phase 380v output;

380v input, 380v output, from 0.4KW-710KW.

2. What is the standard of package?

Below 37kw, it's carton package; 45kw and above, it's the wooden package.

3. Do you accept OEM business?

We accept OEM and ODM with your autherization.

4. What is your market?

We export to the South America, Europe, India, the Middle East, Asia, Africa, etcs.,

5. How to choose suitable VFD for my machine?

Please send us your machine details, we will provide you most suitable model type.

Field Application Photos:

90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control

90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control

Product packaging:

90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control

90kw Delta Equivalent Motor Drive Inverter 50Hz 60Hz 380V 3 Phase VSD Motor Control
