Specifications
Brand Name :
IOTROUTER
Model Number :
ZHC1921
Certification :
CE FCC RoHs
Place of Origin :
Sichuan, CHINA
MOQ :
1PCS
Price :
USD45~48/PCS
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/MONTH
Delivery Time :
1 WEEK
Packaging Details :
270*180*55mm CARTON PACKAGE
Material :
Galvanized Steel Sheet
Interface :
RS485/6DI/4DO/4AI
Protocol :
MODBUS TCP/RTU MQTT
Product Name :
Industrial RS485 Ethernet IO Controller
Function :
Transparent Transmission
Application :
IoT Solutions
Working Voltage :
12V
Module Type :
Ethernet
Customized :
Support
Description

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports For IoT Solutions

Parameters of ZHC1921

POWER
NETWORK
POWER SUPPLY
9~36V
NETWORK TYPE
ETHERNET
Working Current
200mA(aver)/340mA(max)@9V
NUMBER
LAN*1
50mA(aver)/850mA(max)@36V
PORT TYPE
Ethernet signal, RJ45
SERIAL PORT
DO
Serial Port
RS485*1
Standard
(NO,COM)*4
Standard
RS485: 2 Two terminals(A,B)
AC
250V 10A
Baud rate
600~921600bps
DC
30V 10A
Data bits
8, 9
DI
Stop bits
0.5, 1, 1.5, 2
Standard
DI*6 COM*1
Parity bits
NONE,EVEN,ODD
Detect Range
5~50v High 0~2v Low
PI
AI
Number
1
Number
4
Standard
PI*2 COM*1
Standard
AI*4 COM*2
Detect Range
10000Hz
Detect Range
4~20mA


Introduction​ of ZHC1921

ZHC1921 is a network IO product that supports 6-way dry (wet) node detection, 4-way relay (COM, NO) output, 4-way analog (current 4~20mA) detection, and 1-way serial port transparent transmission, compatible with Modbus RTU/TCP protocol. With "remote control" as the core of the function, it is highly easy to use, and users can easily and quickly integrate into their own systems to achieve remote based on Ethernet and RS485 with Local control.

Ethernet: RJ45 interface
DC power supply: 5.5*2.5mm, 9~36V
Reset: Reset button
Serial port: RS485, 5.08mm terminal block plug-in
RELAY: RELAY1~RELAY4 are 4 relay outputs
DI: DI1~DI6 are 6 channels of dry/wet node input detection
PIN: PIN1~2 are 2 pulse input counts
AI: AI1~4 are 4 current input detections

  • Function​ of ZHC1921

The default IP address of ZHC1921 is 192.168.0.65. The configuration requires that the computer and ZHC1921 IP be set to the same IP address segment, otherwise the device and the computer cannot communicate.
ZHC1921 has built-in parameter configuration webpage. Users who use this device do not need to pay attention to the relevant holding registers of the device. They only need to understand the reported data of the device.

Set up ZHC1921 then use the Ethernet cable to connect the network port of the network device (router/switch/other) with ZHC1921. After the device is powered on, observe that the WORK indicator should flash for 3s, indicating that the network hardware environment where the device is located is normal and Ethernet data can be exchanged.

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

Industrial RS485 Ethernet IO Controller With 4DI 4DO 4AI Ports

ZHC1921

RS485 Modbus

√

RS485 Automatic Acquisition

√

Virtual Serial Port

√

Connfiguration Software

√

Threshold Report

√

4 Channel Socket

√

Customize the Follow Logic of Ports

√

MQTT/Modbus RTU/TCP

√
