CWT5005A Professional DIY IOT Gateway Device for Industrial Application

CWT5005A RTU with 2 DI, 2 DO, RS232 standard electrical interface can connect various industrial equipment, such as PLC, meters, sensors, electrical switches.

System Feature

• Industrial NXP 32-bit ARM MCU
• Reliable performance with built-in double watchdog, 24×7 operation
• With signal filtering mechanisms
• Stable reconnection strategy for data transmit
• Synchronize clock with multiple way, Sms, NTP, CwtIO Server
• Configurable action schedule(second, minute, day, week, month)
• Can automatically execute tasks according to preset Events
• Provide configure software, visual programming, over 100 parameters can be set
• Optional exterior rechargable battery for 8-20 hours working when power lost

DI feature

• Monitor dry contact(NO or NC)

DO(T) feature

• Relay drivable output(drive voltage=power supply voltage, Drive current≤500mA)
• on/off/pulse DO by remote control or local event
• Remain down status when power lost

DO(K) feature

• Relay NO contact output(load: 2A / 125VAC,220VDC)
• Remote or local event activate DO on/off/pulse
• Status memory function for power lost

SMS feature

• Can add 10 administrator numbers for alarm and remote control
• Sms alarm when any IO channel triggered or out of preset normal range
• Customizable sms messages, like alarm, receove, report
• Remote get device status or value by sending sms command
• Activate output by sending sms
• Sms report any IO channel’s status or value on schedule
• Remote update parameters by sms
• Sms remind for sim card overdue
• Sms alar for power lost and recover
• Wireless network communication
• Optianal onboard GPRS, 3g, 4g, Wi-Fi module
• Communicate with up to 4 servers(IP or domain) by TCP/IP
• Support post or respond mode for data communication
• Communication protocol: Modbus TCP,http post, Cwt_IO(two-way communication)
• Can forward data between wireless network with RS485 or RS232
