Wifi Data Logging And Acquisition, internet data recorder

System Feature

• Industrial NXP 32-bit ARM MCU
• 24×7 working, soft and hardware Double watchdog
• Dual digital filters for anti-noise
• Stable reconnection strategy for data transmit
• Synchronize clock with multiple way, Sms, NTP, CwtIO Server
• Can set multiple timers(second, minute, day, week, month) to execute actions, e.g. output, upload data, change setting
• Can automatically execute tasks according to preset Events
• Provide configure software, visual programming, over 100 parameters can be set
• Optional inside lithium battery for power lost alarm and keep 8-20 hours working

DI feature

• Monitor dry contact(NO or NC)

DO(T) feature

• Transistor output(drive voltage=power supply voltage, Drive current≤500mA)
• Remote or local event activate DO on/off/pulse
• Remember status when power lost

DO(K) feature

• Relay NO output(load: 2A / 125VAC,220VDC)
• DO can be activated by remote or local schedule
• Status memory function for power lost

AI feature

• 4-20mA (option: 0-5V) in, Sampling frequency: 33Hz, 10-bit precision)
• Transduce 4-20mA(0-5V) to actual value
• Configurable parameters for signal acquisition, alarm, data communication
• Detect connect or disconnect to alarm

SMS feature

• Can add 10 administrator numbers for alarm and remote control
• Send sms alarm when input is triggered or reach alarm level
• Customizable sms messages, like alarm, receove, report
• Query any IO channel’s status or value via sms command
• Activate output by sending sms
• Sms report any IO channel’s status or value on schedule
• Remote update parameters by sms
• Sms remind for sim card overdue
• Power lost and recover alarm by sending sms

Wireless network communication

• Optianal onboard GPRS, 3g, 4g, Wi-Fi module
• Communicate with up to 4 servers(IP or domain) by TCP/IP
• Events(e.g. alarm, timer) trigger upload data
• Support http post, Modbus TCP, CWT protocol over cellular or Wi-Fi
• Transfer RS485 or RS232 Data to wireless network

Modbus feature

• Can be modbus master read/write salve over RS485
• Can work as a modbus slave to be read/write by master(HMI, SCADA etc.)
• Support Modbus RTU to TCP convert over Ethernet or GPRS/3G

TI feature

• Option temperature probe or temperature&humidity probe, support alarm, interlock, data communication
• Can switch ℃ or οF
• Support probe disconnect alarm
