Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
Specifications
Brand Name :
PLINK
Model Number :
Y-C6-DEV-ONX16G
MOQ :
1 set
Price :
To be discussed
Payment Terms :
L/C, D/A, D/P, T/T
Delivery Time :
15-30 work days
NAME :
Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
Keyword :
Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
Memory :
16GB 128-bit LPDDR5 102.4GB/s
AI Perf :
100 TOPS
Module :
NVIDIA Jetson Orin NX
RS-232 :
2*
Size :
120mm×80mm×35mm
MiniPCIe :
2*
Description

Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5

NVIDIA Jetson Orin NX 16GB Module

The most advanced AI computer for smaller, lower-power autonomous machines,NVIDIA Jetson Orin NX provides three independent column address bits to each sub-partition, allowing it access different 32-byte sectors of a GOB between the sub-partitions. It provides connections between a wide variety of clients, supporting their bandwidth, latency, quality-of-service needs, and any special ordering requirements that are needed. The MSS supports a variety of security and safety features and address translation for clients that use virtual addresses.

NVIDIA Jetson Orin NX 16G+FAN+Y-C6 Carrier Board

Based on NVIDIA Jetson Orin NX module, and the module deliver up to 100 TOPS of AI performance in the smallest Jetson form factor, 1,024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores

USB 3.1 Type-A

1

RJ45

1

Micro USB

1

micro SD

1

2 Lane MIPI

2

MiniPCIe

2

CAN

1

HDMI

1

30-pin2.0mm Multifunctional interface design
(GPIO,I2C,SPI,USB,RS-232)

1

NVIDIA Jetson Orin NX Technical Specifications

AI Perf

100 TOPS

GPU

1,024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores

CPU

8-core Arm® Cortex®-A78AE v8.2 64-bit CPU
2MB L2 + 4MB L3

Memory

16GB 128-bit LPDDR5
102.4GB/s

Storage

-
(Supports external NVMe)

CSI Camera

Up to 4 cameras (8 via virtual channels***)
8 lanes MIPI CSI-2
D-PHY 2.1 (up to 20Gbps)

USB

3x USB 3.2 Gen2 (10 Gbps)
3x USB 2.0

Display

1x 8K30 multi-mode DP 1.4a (+MST)/eDP 1.4a/HDMI 2.1

Other I/O

3x UART, 2x SPI, 2x I2S, 4x I2C, 1x CAN, DMIC & DSPK, PWM, GPIOs

Mechanical

69.6mm x 45mm
260-pin SO-DIMM connector

Power

10W - 25W

Embedded SBC Nvidia Jetson Orin Nx Developer Kit 100 TOPS 16GB 128 Bit LPDDR5
