Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128 Channel
Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128 Channel
Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128 Channel
Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128 Channel
Specifications
Brand Name :
Hua Wei
Model Number :
Atlas 300V Pro Video Analysis Card
Place of Origin :
China
MOQ :
1set
Price :
To be negotiated
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
Batch purchase price negotiation
Delivery Time :
15-30 work days
NAME :
Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128-channel real-time HD video analysis
Keyword :
Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128-channel real-time HD video analysis
Half-precision (FP16) :
70 TFLOPS
Integer precision (INT8) :
140 TOPS
Memory :
48GB LPDDR4X
Dimensions (W x H x D) :
169.5 mm x 68.9 mm x 18.45 mm
Weight :
280g
OS :
For details, see the Computing Product Compatibility
Description

Ascend Atlas 300V Pro Video Analysis Card 140 TOPS 48GB LPDDR4X Memory 128-channel real-time HD video analysis

Hua Wei Ascend Altas 300V Pro Video Analysis Card

The Hua Wei Ascend Atlas 300V Pro video analysis card supports an air intake vent temperature from 0°C to 55°C. Internal temperature monitoring points are available. Both in- band and out-of-band modes can be used to monitor the Ascend 310P and storage chip in real time. To ensure heat dissipation, the temperature of the card must be lower than the specification limits when it is working.and the Ascend Atlas 300V Pro video analysis card integrates a general-purpose processor, AI Core, and codec, to provide AI inference and video/image encoding and decoding. Its numerous video analysis channels, fast feature retrieval, and secure boot features facilitate analysis of up to 128 real-time HD videos, JPEG and video hardware encoding/decoding for high-performance image and video applications,Complete device boot chain with an initial boot status for verification, preventing backdoor,Hua Wei Ascend Atlas 300V Pro video analysis card can detect the junction temperature of key components such as the Ascend 310P and storage chips through out-of-band and in-band channels, and detect the temperature of the entire board.

Specifications of the Hua Wei Ascend Atlas 300I Pro inference card

Feature

Specifications

Form factor

HHHL standard PCIe card, supporting full-height and half- height brackets

Memory Capacity

48 GB LPDDR4X

Bit width

384 bits
Rate

4266 Mbit/s

Total bandwidth

204.8 GB/s

Half-precision (FP16)

70 TFLOPS

Integer precision (INT8)

 140 TOPS

Encoding/ Decoding capability

H.264/H.265 decoder hardware decoding, 128-channel 1080p 30 FPS or 16-channel 4K 60 FPS

H.264/H.265 encoder hardware encoding, 24-channel 1080p 30 FPS or 3-channel 4K 60 FPS

JPEG decoding capability of 4K 512 FPS and encoding capability of 4K 256 FPS, maximum resolution of 8192 x 8192
Dimensions

169.5 mm x 68.9 mm x 18.45 mm
Weight 280g

Heat Dissipation Specifications

The Hua Wei Ascend Atlas 300V Pro video analysis card supports an air intake vent temperature from 0°C to 55°C. Internal temperature monitoring points are available. Both in- band and out-of-band modes can be used to monitor the Ascend 310P and storage chip in real time. To ensure heat dissipation, the temperature of the card must be lower than the specification limits when it is working.

Integrated in servers for AI inference
