ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles
ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles
ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles
ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles
Specifications
Brand Name :
NVIDIA
Model Number :
AGX xavier 32G (900-82888-0040-000)
Place of Origin :
USA
MOQ :
1pcs
Price :
$1100-$1200/pcs
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
15-30 work days
Delivery Time :
15-30 work days
Packaging Details :
100mm x 87mm 699 pin Molex Mirror Mezz Connector Integrated Thermal Transfer Plate
NAME :
ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles
Keyword :
ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles
AI Performance :
32 TOPS
GPU :
NVIDIA Volta™ architecture with 512 NVIDIA CUDA cores and 64 Tensor cores
CPU :
8-Core Carmel ARM v8.2 64-Bit CPU, 8 MB L2 + 4 MB L3
Memory :
32 GB 256-bit LPDDR4x 136.5GB/s
Storage :
32 GB eMMC 5.1
DL Accelerator :
2x NVDLA 10 TOPS (INT8)
Vision Accelerator :
2x PVA
Power :
10W | 15W | 30W
Size :
100mm x 87mm
Description

ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles

NVIDIA Jetson AGX Xavier Module

Volta GPU + Carmel CPU + 32GB LPDDR4x + 32GB eMMC

The NVIDIA Jetson AGX Xavier module blends industry leading performance, power efficiency, integrated deep learning capabilities and rich I/O to enable emerging technologies with compute- intensive requirements. Designed for applications converging on artificial intelligence (AI), computer vision (CV) and advanced graphics, the AGX Xavier series module is ideal for (but not limited to): Intelligent Video Analytics (IVA), Robotics, Virtual Reality (VR), Augmented Reality (AR) and Portable Medical Devices.

One End-to-End, Modular, and Scalable Platform

Autonomous vehicles (AV) powered by AI are changing the way we move people and goods all over the world.

ODM 32G Nvidia Jetson Agx Xavier Industrial Module for Autonomous Vehicles

NVIDIA Jetson AGX Xavier 32G Module Technical Specifications

Shock Non-operational: 340G, 2 ms, half sine, 6 shocks/axis, 3 axes
Vibration Non-operational: 10-500 Hz, 5G RMS, 8 hours/axis
Temperature Operational: -25°C to 80°C at TTP
Humidity Non-operational: 95% RH, -10°C to 65°C, 10cycl/240 hours
Operating Lifetime 5 Years

AI Performance 32 TOPS (INT8)

GPU

 NVIDIA Volta™ architecture with 512 NVIDIA CUDA® cores and 64 Tensor cores

CPU

 8-core NVIDIA Carmel Armv8.2 64-bit CPU
8MB L2 + 4MB L3
DL Accelerator 2x NVDLA
10 TOPS (INT8)
Vision Accelerator 2x PVA
Memory 32GB 256-bit LPDDR4x
136.5GB/s
Storage 32 GB eMMC 5.1
CSI Camera Up to 6 cameras (36 via virtual channels)
16 lanes MIPI CSI-2, 8 lanes SLVS-EC
D-PHY 1.2 (up to 40Gbps)
C-PHY 1.1 (up to 62Gbps)
Video Encode 4x 4K60 (H.265)
8x 4K30 (H.265)
16x 1080p60 (H.265)
32x 1080p30 (H.265)
30x1080p30 (H.264)
Video Decode 2x 8K30 (H.265)
6x 4K60 (H.265)
12x 4K30 (H.265)
26x 1080p60 (H.265)
52x 1080p30 (H.265)
30x 1080p30 (H.264)
UPHY 8x PCIe Gen4 | 8x SLVS-EC
3x USB 3.1
Single Lane UFS
Networking 10/100/1000 BASE-T Ethernet
Display Three multi-mode DP 1.2a/e DP 1.4/HDMI 2.0 a/b
Other I/O USB 2.0
UART, SPI, CAN, I2C, I2S, DMIC & DSPK, GPIOs
Power 10W | 15W | 30W
Mechanical 100mm x 87mm
699 pin Molex Mirror Mezz Connector
Integrated Thermal Transfer Plate
