Specification
Input voltage | 220V-50HZ/110V-60HZ |
Input power | 150W |
Output power | 0-100%±10% |
Output frequency | 30MHz |
Output voltage | AC 30-150V |
Treatment of needle wire | 0.01mm(Diameter) |
Output mode | Continuous and pulsed two modes |
Liquid crystal display | 8.4Inch |
Operating mode | Touching screen |
Dimensions | 395×460×130mmg |
Installation
In1, instrument placed steadily at room temperature - humidity of not more than 60% 10-40, clean operation room or in the treatment of indoor, or will cause the instrument components cannot repair damage.
In2, a foot switch installation will foot switch plug gaps in alignment apparatus "F00T SWITCH" interface directly after inserting holes, and the locknut screwing clockwise ( Note: during the tightening process for plug and screw, until cannot insert and tighten, prevent virtual connection ).
In3, a power connection will power line connecting apparatus is directly inserted into the apparatus"220V10A50HZ" interface, and confirm the installation is firm.
In4, the treatment head connecting the treatment head connecting apparatus is inserted directly into the instrument of high frequency interface, clockwise to tighten, and confirm the installation is firm, prevent false contact.
In 5, connect the power first confirm the emergency stop switch in the up state, whether it be an emergency stop switch clockwise (in the direction indicated by the arrow ) rotation to bounce state, the power supply plug access to good three core power socket, the key is inserted into and rotated clockwise90 degrees to" ON" status; this apparatus electric operation.
