24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
Specifications
Brand Name :
Colable
Model Number :
COL5011F
Certification :
CE
Place of Origin :
Made in China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union etc
Supply Ability :
500sets per Month
Delivery Time :
2-5 working days
Packaging Details :
Standard Export Carton with foam
Input :
8/12/16/24 HDMI + 2*ASI
Output :
8/12/16/24*SPTS & 4*MPTS + 2*ASI
IP Protocol :
UDP & RTP
Video Encoding :
MPEG-4 AVC/H.264
Audio Encoding :
MPEG1 Layer2
Resolution :
Input: max 1080P, Output: "P" output
Management :
Network WEB management
Applications :
Digital TV Headend, CATV, IPTV, DTT, DSTV etc
Description

24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F

8/12/16/24*HDMI input to 8/12/16/24*SPTS or 1MPTS IP out

Features for MPEG-4 AVC/H.264 Encoder


 8/12/16/24 HDMI input, MPEG-4 AVC/H.264 Video encoding
 8/12/16/24 HDMI inputs with 8/12/16/24 SPTS &1 MPTS output, IP output over UDP& RTP protocol
 2 ASI inputs
 2 ASI Independent output (optional) as copy of 1MPTS
 Support "Null PKT Filter" function
 Support PID Remapping/ PCR accurate adjusting
 LCD, key function

 Control via web management, and easy updates via web

Specifications for HD H.264 Encoder

Input
HDMI (8/12/16/24 HD.MI)
2 ASI inputs
Output
2 ASI output
IP output: 8/12/16/24 HDMI inputs with 8/12/16/24 SPTS and 4 MPTS output,
IP output over UDP and RTP protocol
Video
Encoding
MPEG-4 AVC/H.264
Resolution
Input:1920*1080_60P, 1920*1080_60i,
1920*1080_50P, 1920*1080_50i,1280*720_60P, 1280*720_50P,720*576_50i,720*480_60i,
Output:1920*1080_30P,1920*1080_25P,1280*720_30P,1280*720_25P,720*576_25P,720*480_30P
Bit-rate
1Mbps~13Mbps(each channel)
Rate Control
CBR
Audio
Encoding
MPEG1 Layer2
Sampling rate
44.1KHz and 48Khz
Bit-rate
64kbps ,128Kbps,192kbps,224kbps,256kbps,320kbps,384kbps
Resolution
24-bit
Audio Gain
0-255 Adjustable
Multiplexing
Maximum PID Remapping
180 output pids per channel
Function
PID remapping ( automatically or manually)
Accurate PCR adjusting
System function
Network management(WEB)
Chinese and English language
Ethernet software upgrade

Front Panel for HD H.264 Encoder

24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F

Rear Panel for HDMI H.264 Encoder

24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F

Packing for MPEG-4 AVC/H.264 Encoder

24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F 24 Channels MPEG-4 AVC/H.264 Encoder HDMI IPTV Streaming Encoder COL5011F
