24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F
24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F
24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F
24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F
Specifications
Brand Name :
Colable
Model Number :
COL5011F
Certification :
CE
Place of Origin :
Made in China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union etc
Supply Ability :
500sets per Month
Delivery Time :
2-5 working days
Packaging Details :
Standard Export Carton with foam
Product Name :
HD H.264 Encoder
Input :
8/12/16/24 HDMI + 2*ASI
Output :
8/12/16/24*SPTS & 4*MPTS + 2*ASI
IP Protocol :
UDP & RTP
Video Encoding :
MPEG-4 AVC/H.264
Audio Encoding :
MPEG1 Layer2
Resolution :
Input: max 1080P, Output: "P" frame
Management :
Network WEB management
Description

24 Channels HD H.264 Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F

Description

COL5011F HD H.264 encoder is a professional audio video streaming hardware device which includes encoding, multiplexing functions and supports 8/12/16/24 HDMI optional input, 1000M IP output (MPTS and SPTS output). The encoder is widely used in all kinds of digital tv, video system, which is the preferred device for content source encoding of DTV broadcasting system to address the ever-increasing demand for more premium viewing experiences.

Features

  • 8/12/16/24 HDMI input, MPEG-4 AVC/H.264 Video encoding
  • 8/12/16/24 HDMI inputs with 8/12/16/24 SPTS &1 MPTS output, IP output over UDP& RTP protocol
  • Supports 1920*1080_60P, 1920*1080_60i resolution.
  • 2*ASI input, 2 ASI Independent output (optional) as copy of 1MPTS
  • Support “Null PKT Filter” function
  • Support PID Remapping/ PCR accurate adjusting
  • LCD, key function
  • Control and upgrade via web, it's easy to operate& management.

Specifications

Input HDMI (8/12/16/24 HDMI)
2 ASI inputs
output 2 ASI output

IP output: 8/12/16/24 HDMI inputs with 8/12/16/24 SPTS and 4 MPTS output,

IP output over UDP and RTP protocol
video Encoding MPEG-4 AVC/H.264
Resolution

Input:1920*1080_60P, 1920*1080_60i,

1920*1080_50P, 1920*1080_50i,1280*720_60P,

1280*720_50P,720*576_50i,720*480_60i,

Output:1920*1080_30P,1920*1080_25P,1280*720_30P,

1280*720_25P,720*576_25P,720*480_30P
Bit-rate 1Mbps~13Mbps(each channel)
Rate Control CBR
Audio Encoding MPEG1 Layer2
Sampling rate 44.1KHz and 48Khz
Bit-rate 64kbps ,128Kbps,192kbps,224kbps,256kbps,320kbps,384kbps
Resolution 24-bit
Audio Gain 0-255 Adjustable
Multiplexing Maximum PID Remapping 180 output pids per channel
Function PID remapping ( automatically or manually)
Accurate PCR adjusting
System function Network management(WEB)
Chinese and English language
Ethernet software upgrade
Miscellaneous Dimension (W*L*H) 550mm*5050mm*140mm
Weight 6kg
Environment 0~45℃(work)；-20~80℃(storage)
Power requirements AC100~240V,50/60Hz

Packing for HD H.264 Encoder

24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F

24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F24 Channels Ip Video Encoder Video Streaming Hardware H.264 IPTV Encoder COL5011F
