Specifications
Brand Name :
iqualitrol
Model Number :
XBrin-3000BH
MOQ :
1 Set
Payment Terms :
T/T, Western Union
Supply Ability :
20 Sets per Month
Delivery Time :
20 Working Days
Packaging Details :
Plywood Box
Vertical Space :
Max Height of Specimen 340mm
Throat :
Max Horizontal Space 250mm
Microscope :
Analogue 20x Microscope
Range :
Brinell Range (8-650) HBW
Loading Force :
187.5Kgf, 250Kgf,750Kgf, 1000Kgf, 3000Kgf
Loading Style :
By Weights
Description


Vertical Space 340mm Brinell Hardness Testing Machine 5 Steps Loading Force Max 3000Kgf


Features:
1, Electronic communication switch. Solid construction, good rigidity, precise, reliable, durable, high efficiency.


2, High precision reading microscope measurement system.


3, Widely used in quality control, strong adaptability to working environment.

Application:
Testing Brinell hardness of ferrous, non-ferrous metal and bearing alloy materials. Wide application range, especially used in precision measurement of parallel plane. What’s more, measurement of curved surface is stable and reliable.

Technical Specifications:

Product Name Brinell Hardness Tester
Model XBrin-3000BH
Test Force Kgf 250Kgf, 500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf
N 2452N,4900N, 7355N, 9800N, 14700N, 29400N
Measuring Range (8-450) HBS, (8-650) HBW
Hardness Display Check the table of Brinell Hardness scale
Microscope Analogue 20x Microscope
Max height of Specimen 340mm
Instrument Throat 250mm
Dimension 820 x268 x980mm
Gross/Net Weight 400Kg/360Kg
Execution Standard GB/T231.2, JJG150, EN-ISO 6506,
ASTM E10-12, JIS Z2243
Accuracy of Brinell hardness testing
Hardness Range Max Tolerance Repetition
HBW≤ 125 ≤± 3.5％ ≤ 3.5％
125＜HBW≤225 ≤± 2.5％ ≤ 3.0％
HBW＞ 225 ≤± 2.0％ ≤ 2.5％


Standard Delivery:

Instrument Main body Ø10mm Ball Indenter Ø200mm Flat anvil
Analogue 20x Microscope Ø5mm Ball Indenter Ø60mm Flat anvil

Hardness Block
HBW 10/3000

 Ø2.5mm Ball Indenter Ø40mm V-shape Anvil

Hardness Block
HBW 5/750

 Power Cable Accessories Box
Anti-dust Cover Operation Manual Qualified Certificate
