Specifications
Brand Name :
iqualitrol
Model Number :
iVick-452MW
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
20 Sets per Month
Delivery Time :
3 Working Days
Packaging Details :
Plywood Box
Configuration :
Limitation Set Alarm, Thermal Printer
Energy Saving :
Auto standby mode after 5min
Test Space :
Height 90mm, Throat 110mm
Scales :
HV and HK
Description

Digital Eyepiece 10X Micro Vickers Hardness Tester with
Built-in Printer Motorized Turret

Technical Data Download:
iqualitrol Micro Vickers Hardness Tester iVick-452MW

Brief Introduction:

iVick-452HW equips with digital measuring eyepiece, just press the eyepiece button after measuring the indentation length, it can automatically get the hardness value and shows on the screen.

Test results can be printed out by the built-in printer, and with RS232 interface for connecting to the computer.

Support Knoop hardness testing by install optional Knoop indenter, and support LCD video measuring device and CCD image automatic measuring system.

Technical Specification:

Model iVick-452HW iVick-452MW
Test Force gf 10gf, 25gf, 50gf, 100gf, 200gf, 300gf, 500gf, 1000gf
N 0.098N, 0.246N, 0.49N, 0.98N,
1.96N, 2.94N, 4.90N, 9.80N
Test Range 1HV~2967HV
Test Mode HV/HK
Loading Method Automatic (Loading/Dwell/Unloading)
Turret Manual Turret Automatic Turret
Conversion Scale HK, HRA, HRB, HRC, HRD, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HBW
Data Output Built-in Printer, RS232 Interface
Objective 10x (Observe), 40x (Measure)
Eyepiece 10x
Total Magnification 100x, 400x
Resolution 0.0625μm
Dwell Time 0~60s
Light Source Halogen Lamp
X-Y Test Table Size: 100×100mm; Travel: 25×25mm;
Resolution: 0.01mm
Max. Height of Specimen 100mm
Throat 98mm
Power Supply AC220V/50Hz/1Ph
Execute Standard ISO 6507, ASTM E384, JIS Z2244, GB/T 4340.2
Dimension 480×325×545mm, Packing Dimension: 600×360×800mm
Weight Net Weight: 31kg, Gross Weight: 44kg

Packing List:

Instrument Main Body 1 set 10x Digital Eyepiece 1 pc
Diamond Vickers Indenter 1 pc 10x, 40x Objective each 1 pc
Weights 6 pcs Weight Axis 1 pc
Cross Test Table 1 pc Flat Clamping Test Table 1 pc
Thin Specimen Test Table 1 pc Filament Clamping Test Table 1 pc
Horizontal Regulating Screw 4 pcs Level 1 pc
Instruction Manual 1 copy Halogen Lamp 12V,15~20W 1 pc
Power Cable 1 pc Screw Driver 2 pcs
Hardness Block 400~500 HV0.2 1 pc Hardness Block 700~800 HV1 1 pc
