HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
Specifications
Brand Name :
Shi Zun
Model Number :
HK2M-H1901
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100+pcs+day
Delivery Time :
10 working days
Packaging Details :
60mm× 9mm× 9.8m
Photosensitive chip :
RGB CMOS1/2.7"
Pixel Size :
3.0μm x3.0μm
SNR max :
TBD dB
Max Dynamic Range :
90 dB
Minimum illumination :
0.1Lux at F12
F/No :
2.0
EFL :
4.3mm
FOV :
73°
IR :
650±10nm
Lens Construction :
4P+IR
Maximum resolution and frame rate :
1920*1080(30fps)
Other optional resolution ratio :
640* 480 (30fps), 800* 600(30fps), 1280* 720(30fps)
Support format :
YUV / MJPG
USB power supply voltage :
5V±5%
Connect the interface :
1* USB-5pin-1.0mm
Interface speed :
480mb/s
Operating systemrequest :
WinXP, Win7, Linux or Vista and android4.1
Power Consumption :
Regular work: 0.5W
storage temperature :
0°C to 50°C
Working temperature :
-10°C to+60°
structure size :
60mm× 9mm× 9.8m
Description

HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR

HK2M-H1901 Wide Dynamic Range Camera Module Features:

  1. USB 2.0 Interface
  2. 2-Megapixel Resolution High Definition Camera
  3. Compact and Exquisite Design
  4. 2-Megapixel High Definition Imagery for True and Delicate Visuals
  5. Anti-drag, Low Noise, Clearer Imaging
  6. USB 2M Wide Dynamic Range, Effectively Addresses Overexposure from Strong Light and Low Light Conditions
  7. Dual-Eye Live Body Detection Camera
  8. Dual 1/2.5 Large Size SENSORS
  9. With Illumination Light + Infrared Night Vision Light

HK2M-H1901​ Wide Dynamic Range Camera Module Parameter:

Connect the interface: 1* USB-5pin-1.0mm
Interface speed: 480mb/s
Maximum resolution and frame rate: 1920* 1080(30ps)
Other optional resolution ratio: 640* 480 (30fps), 800* 600(30fps), 1280* 720(30fps)
Support format: YUV/ MJPG
Max Dynamic Range 90dB
F/No: 2.0
EFL: 4.3mm
FOV: 73°
Lens Construction: 4P+IR
Power Consumption: Regular work: 0.5W
Operating systemrequest: WinXP, Win7, Linux or Vista and android4.1

HK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IRHK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IRHK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IRHK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IRHK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IRHK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IRHK2M-H1901 Outdoor Wide Dynamic Backlight-Resistant Camera Module Lens Construction 4P+IR
