43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy
43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy
43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy
43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy
Specifications
Brand Name :
YCLTOUCH
Model Number :
LV-43
Certification :
RoHS, ISO 9001:2000, ce, EMC, LVD
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20000/month
Delivery Time :
1-3 Days
size :
43 inch
Size :
Customizing
Name :
IR Multi Touch Frame
Touch Screen :
IR Multi Touch Screen
Color :
black
Warranty :
12 months
Response time :
≤10ms
Minimum Recognition Point Size :
4mm*4mm
Description

43 Inch Ir Touch Screen frame 20 Touch Points Open panel Frame Overlay Kit

IR Touch Frames

  • Infrared(IR) Touch Frame is designed to retrofit to existing non-touch displays. Our unique IR interactive touch frames offer a true multi-touch experience transforming any screen or surface into an interactive display. Whether it’s a new touch display installation, or retrofitting touch to an existing screen, video wall or table, an interactive touch overlay is the perfect choice,wide application in Retail, Hospitality, Education, Showrooms, Corporate, Offices, Exhibitions, Digital Signage etc..
  • Affordable and widely use
  • 20 points touch
  • 15-500” and sizes customized
  • Fast response and easy integration

Specification

Specification of Infrared Touch Screen
Touch Screen Size 43
Touch Points 20-point touch
Minimum Recognition Point Size 4mm*4mm
Supporting resolution 32768×32768
Touch Response Time(Multi touch) 10-15ms
Touch Response Time(One touch) 7ms
Input method Any opaque touches, such as fingers, brushes, etc.
Calibration 4-point calibration
Number of clicks nfinite times
Touch pressure No pressure requirement
Interface type 1.5 m USB cable receptacle, the receptacle 5P
Line length 1.5m
Frame Material Aluminium alloy
Glass Material Toughened glass
Characteristic Easy installation, strong compatibility
Scanning frequency >110Hz
Power supply mode USB 5.0V
communication interface USB 2.0
Working Voltage and Current 4.75~5.25V , ≤200mA
Humidity Up to 90% RH from 0°C to +40°C, non-condensing
Temperature Range Working temperature:-10℃~50℃,Storage temperature:-20℃~60℃
LED Lifetime 60000hours
Fault-tolerant Able to work if less than10% non-consecutive sensors are damaged
Anti-light Interference Excellent
Firmware Upgrade USB Upgrade: Windows 8,Windows 7
ESD EN 6100-4-2 2008:3 level.4KV contact discharge and8KV air discharge
Support OS( One touch) WindowsXP,MacOS.Linux
Support OS (Multi touch) Windows10,Windows8,Windows7,Andriod

What is Multi-Touch?

Multi-touch refers to a touch system’s ability to simultaneously detect and resolve a minimum of 2+ touch points. All 2 or more touches are detected and fully resolved resulting in a dramatically improved touch experience

Product Application

43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy

company Imformation

Welcome to our company:Shenzhen Yongchuangli Electronic Technology Co., Ltd.

Shenzhen Yongchuangli Electronic Technology Co., Ltd.is a high-tech enterprise specializing in R&D, production and sales of infrared PCBA sets, touch frames, touch screens, splicing screens, interactive intelligent electronic whiteboard (projection type).Acquired nearly 10 domestic practical technology soft work, truly achieve 32 touch solution providers. The company focuses on interactive touch application, adheres to the "independent innovation technology beyond" development strategy, has a strong technical force of R&D team, and has a number of core technology solutions.

Infrared touch box, multi-touch screen and other core products have the following characteristics: high resolution, fast response, support for multi-touch operation, one-hand occlusion does not affect touch, support gesture switching dual system, the narrowest and thinnest border, drive-free support for multiple systems, suitable for Windows, Mac OS, Android, Linux operating system.

Quality products and all-round service are the basis for us to win the market. We patiently listen to every customer's suggestions and opinions, so that we continue to forge ahead, we always uphold the customer first, dedicated service!

The series of products produced by the company conform to UL, FCC, ROHS and Reach standards. The company has passed the ISO 9001:2015 international quality management system certification.

Innovation embellishes the future.

43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy

Packing and Delivery

43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy43 Inch IR Touch Screen Frame 20 Points 4mm*4mm Aluminium alloy

FAQ

1 who are we?
We are based in Guangdong, China, start from 2013,sell to Domestic Market(00.00%),Western Europe(00.00%),Southeast Asia(00.00%),South Asia(00.00%),Mid East(00.00%),North America(00.00%). There are total about 101-200 people in our office.

2 how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3 what can you buy from us?
Capacitance Touch Screen,Infrared Touch Screen,Interactive Whiteboard,Infrared PCBA Module

4 why should you buy from us not from other suppliers?
Acquired nearly 10 domestic practical technology soft,Achieve 32-point touch,High resolution and fast response,Single-handed occlusion does not affect touch, support switching dual systems, thin border, drive-free,For Windows, Mac OS, Android, Linux.

5 what services can we provide?
Accepted Delivery Terms: FOB,DDP；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
