Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN
Specifications
Brand Name :
Speedata
Model Number :
KT45Q-B2-C8M-TCS1G-PE48
Certification :
CCC,CQC,ISO9001,IP65,CE
Place of Origin :
Beijing Speedata in China
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram,PayPal
Supply Ability :
5000pcs/months
Delivery Time :
3-7 work days
Packaging Details :
independent packing with standard carton box,accessories(battery/charger/USB data cable/protection cover/hand strap)
Fingerprint reader :
FBI FIPS-201 Compliant (EIM)
WWLAN :
FDD B1B3B7 TDD B38B39B40 WCDMA B1B2B5B8 EVDO BC0 GSM B2B3B5B8
Dimension :
175*76*27mm
GPS :
Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
Bluetooth :
v2.1+EDR/ 3.0+HS / v4.0 Low Energy (LE)
Protection class :
IP65
External Interface :
USB HOST/RS232(Customized)
Drop resistance level  :
1.5m
Description
Mobile Printers All in one with Best Portable Multifunctional fingerprint collector and 4G WWLAN

Specifications of KT45Q

1,4.5inch high-definition IPS LCD capacitive touch screen to meet your visual enjoyment

2,8MP camera with high definition ,it's easy to collect all kinds of image information

3,Support 1D/2D barcode scanning,LF/HF/UHF RFID/fingerprint reading, terminal printer, MSR, PSAM function etc

4,Android Operation System, More Stable and Reliable,provide complete SDK and technical support to make further app development easily

5,Special structure and external cushion protection design, solid and waterproof body shape

6,Matched with the machine seat charger, to ensure the charging interface durable,it's more quicker and easier

7,IP65 Industrial Class, 1.5M drop protection

8,Multiple Functions optional: card reader, printer, fingerprint, infrared reader, temperature, etc

Paramaters of KT45Q
Development Environment
Operating System Android 5.1
SDK Software Development Kit
Language Java
Fundamental Characteristics
CPU Quad-core 1.3Ghz ARM® Cortex-A53 (LPDDR2 and LPDDR3)
Memory 1GB DDR3 RAM + 8GB Frash ROM
Storage Micro SD/TF card max.32GB expansion
Display 4.5-inch IPS 480 * 854 Multi-point touch capacitive screen
Communications
4G WWLAN FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8
WiFi 2.4Ghz 802.11 b/g/n
G-Sensor Yes
Bluetooth V2.1+EDR / 3.0+HS / V4.0 Low Energy(LE)
GPS Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
DGPS (please check options)
Physical Characteristics
Dimensions 175 * 76 * 28mm
Weight More 400g (includes main battery)
Expansion Slots 1*PSAM, 2*SIM
Battery rechargeable li-ion battery 4500mAh 3.7V
Or rechargeable li-ion battery 2250mAh 7.4V (if with printer)
500hours standby time, Up to 6hours calling time, 4hours charging time
Camera 8MP Camera
Video Support still image and video capture
Audio 3.5mm 4way plug
Keypad Front 17keys, Side 4keys
Interfaces 1*MicroSD/TF, 1*Audio Jack, 1*Micro USB, 1*Power Jack
USB Host (Optional), RS-232 interface (Optional)
User Environment
Operating Temp. -10 to 50℃
Humidity 10%RH - 90%RH (Non-condensing)
Protection class IP65
Drop resistance level 1.5M
Barcode scanners (optional )
1D Linear Scanner (Optional)
1D scanner Symbol SE955 (Optional 1)
Newland EM1300 (Optional 2)
Honeywell N4313 (Optional 3)
2D Imager Scanner (Optional)
1D/2D scanner Symbol SE4500 (Optional 1)
Newland EM3000 (Optional 2)
Data Modules
RFID readers (optional)
LF RFID reader 134.2khz, ISO 11784/11785, FDX-B/HDX (Optional 1)
125khz (Optional 2)
HF RFID reader 13.56MHz, ISO 14443A/B, ISO 15693
NFC reader Include 13.56MHz, ISO 1443A/B
UHF RFID reader 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 chipset
860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with R2000 chipset, Long distance reader
Biometric fingerprint Reader (optional )
Fingerprint Sensor Crossmatch TCSIG (meet FBI FIPS201 ) (Optional 1)
Fingerprint Sensor Crossmatch TCS1B (meet STQC ) (Optional 2)
Fingerprint Sensor UPEK TCSI (meet FBI's FIPS-201)
Fingerprint Sensor UPEK TCS2SS
Other Modules (optional )
DGPS Ublox LEA-6T (with RTK)
PSAM ISO7816 (SIM card interface)
MSR Compatible with one, two, three track(without PCI, EMV security certification)
IC card reader ISO7816 ID-1
Printer Integrete 2inch Direct thermal line printing
Far Infrared Meter Reading IEC62056-21 (IEC1107) communication protocol
433Mhz Require customers to provide 433Mhz wireless modules or specifications
Zigbee Require customers to provide 433Mhz wireless modules or specifications
Printer Module Specifications
Printing method Direct thermal line printing
Paper width 57mm
Print width 48mm
Resolution Ration 8 dots/mm (384 dots/line )
Life of printing head 5,000,000 -15,000,000 character lines
Printing speed 40-60mm/sec
Character size 8*16dots , 12*24dots
Paper supplied 57mm wide , 22mmø
Interface Serial RS232C/TTL
Operating temperature 0℃--50℃
Storage temperature -20℃ -- 60℃
Operating humidty 10%--80%
Storage humidty 10%--90%
Fingerprint Module Specifications
TYPE1 TCS1G
Touchchip Sensor Interface 8 bit parallel interface
20-pin flex connector
Power(typical) 4.5-4.6V supply
20mA during capture
Touchchip Module Interface Options 5-soldier pads for USB only @ 5V
12-pin flex: USB,SPI,UART @ 3.3V (optional)
Power(typical) 3.0V-3.6V
80mA(capture,match)
Standby(USB) :1350 uA
Standby(UART/SPI) : 1150uA
Wake-up time: <15 ms (Sleep to imaging)
Digital ID Hardware Engine Biometric Companion Processor - 1:1 match time ~50uS per template
- 1:100 match time <2s typ.
- On-board NVM storage for up to 100 templates
- More than 100,000 erase/write cycles
- More than 20 years data retention
Common Spec Fingerprint Image 12.8×18.0mm(256×360pixels)
508dpi,8-bit greyscale
Sensor Coating gold coating,FBI FIPS-201 Compliant (EIM)
Package Size 23 mm x 35 mm x 4.1 mm
ESD IEC 61000 - 4.2 level 4, +/- 15KV air, +/- 8IKV contact
Ingress Protection IP 65 (water/dust protection)
Environmental • Operating temp: -30 to +70 C
• Storage temp: -30 to + 125 C
• Humidity: 5% - 93% non-condensing
• ROHS, low halogen

Advantages

1. R & D technology support

1.Our R&D team have experienced software & hardware high tech engineers, 27% of the whole employees, who have professional background in Electrical Engineering.

2.Since its reasonable structure and professional ability,our products become more stable and compatible.

As expected, we have built up a strong spirit of collaboration teamwork and gained a good reputation from our customers.

2. Strong customized capabilities

Speedata serves wide industries and fields, such as the electric power, mapping, e government, logistics, traceability management, fixed asset management.etc. we have accumulated rich and extensive experiences in those industries.

we pay more attention to design personalized software and hardware products as well as whole solutions development.

The products will develop in the direction of the platformization and modularization and put technology into the public platform to simplify for its secondary development.

At the same time, we supply core board customization, sensors and module development to combine with platform quickly to meet customers demand.

Company Information

Beijing SPEEDATA is committed to provide advanced data acquisition terminal in each field. after long-term accumulation, we have built a comprehensive and professional technology team and service, has a wealth of experience in the field .whatever you need GIS ,Automatic identification technology or mobile devices , our highly technical conformity ability and professional service will provide the most suitable solution for you.


Win-win cooperation is our pursuing goal ,through establish close cooperation relations with software system integration in the industrial field,build a complete perfect information management system from the front to the background. Successively for logistics ,FMCG, member management , electric power, surveying and mapping , agriculture, water conservancy,medical,petrochemical inspection,communication and many other industries provide advanced ,complete industry solutions and equipment .

Applications

We provide free SDK for corresponding functional PDA, like barcode demo, fingerprint demo, printer demo, RFID demo, IC card demo etc.

We have a strong R&D team for not only hardware but also software, have developed the following solutions for our customers:

Cold-chain logistics and transportation tracking

meat product tracking

Mobile police service

Fixed-Assets management

Tickets checking

More industrial solutions of management systems as following:

  1. Logistics & Express
  2. Transportation
  3. Electric meter readings
  4. Network community management
  5. Storage & Distribution
  6. Petrochemical inspection
  7. Geomatics & Surveying
  8. Product tracking
  9. Health & pharmaceutical industry
  10. Mobile police service
  11. Tobacco Logistics
  12. Fixed-assets management
  13. Surveying and mapping
  14. Agriculture
  15. Water conservation
  16. Animal tracking & research
  17. Retail chain
