Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Specifications
Brand Name :
Speedata
Model Number :
KT45-C8M-TCS1
Certification :
ISO9001,CCC,CQC,IP65
Place of Origin :
Beijing,China
MOQ :
1 set
Payment Terms :
Western Union, MoneyGram,Paypal
Supply Ability :
5000 pcs per month
Delivery Time :
3-7 days after payment
Packaging Details :
1 unit independent packing with standard carton box,accessories(battery/charger/USB data cable/protection cover/hand strap)
OS :
Android 4.4.2
CPU :
Quad-core 1.3Ghz ARM® Cortex-A7 MPCoreTM (LPDDR2 and LPDDR3)
WWLAN :
GSM band 850/900/1800/1900MHz, Class 12 GPRS, EDGE UMTS 850/900/1900/ 2100MHz HSPA
Memory Capacity :
8GB ROM,1GB RAM
Display :
4.5 inch IPS 480*854
Touch screen :
Multi-point touch capacitive screen
GPS :
Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
Bluetooth :
v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi :
2.4Ghz 802.11 b/g/n
External Interface :
USB HOST/RS232(Customized)
Protection class :
IP65
Drop resistance level  :
1.5m
Camera :
8MP
Battery :
rechargeable Li-ion battery 4500mAh
Weight :
175*76*27mm>400g with battery (according config)
Description
Mobile Handheld PDA Biological fingerprint reader With Wifi Bluetooth GPRS GPS
Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Product Description

SPEEDATA KT45 is a 4.5 inch screen handheld terminal with multifuctional extension module. Support 1D/2D barcode reader,LF/HF/UHF RFID Scanner,Fingerprint collection,Thermal printer,PSAM,MSR function etc and accept customized combination.

SPECIFACTION

KT45 Android with Camera+fingerprint
model number : KT45-C8M-TCS1
android OS
OS Android 4.4.2
Hardware
Core board CPU Quad-core 1.3Ghz
ARM® Cortex-A7 MPCoreTM (LPDDR2 and LPDDR3)
WWLAN GSM band 850/900/1800/1900MHz, Class 12 GPRS, EDGE
UMTS 850/900/1900/ 2100MHz HSPA
Flash ROM 8GB
RAM 1GB DDR3
Motherboard
Display 4.5inch IPS 480*854
touch screen Multi-point touch capacitive screen
Form Factor Bar type classical PDA,Industrial appearance
GPS

Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN).

Support Full AGPS
Bluetooth v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi 2.4Ghz 802.11 b/g/n
MSR(optional )

Compatible with one, two, three track. (without PCI, EMV security

certification.)
PSAM(Optional) ISO7816 (SIM card interfance)
IC card reader(optional) ISO7816 ID-1
Fingerprint reader TCS1
Printer 2 inch Direct thermal line printing
Far Infrared Meter Reading (Optional) IEC62056-21(IEC1107) communication protocol
433Mhz module(Optional)

Require customers to provide 433Mhz wireless modules or

specifications.
zigbee (Optional) Require customers to provide 433Mhz wireless modules or specifications.
RFID Reader option 1

LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) -- reading

distance 10cm
option 2 LF RFID(125KHz) -- reading distance 10cm
option 3 HF RFID(13.56MHz ISO 14443A/B ISO 15693) -- reading distance 5cm
option 4 NFC(include 13.56MHz ISO 14443A/B )
option 5

UHF RFID 860-960MHZ ISO 18000-6C---with IMPINJ R2000

shipset 60mm antenna---reading distance up to 5m
option 6

UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A

,B compatibility in direct mode----with AS3992 shipset -- reading

distance up to 3m
barcode scanner option 1 NEWLAND:EM1300(1D barcode reader-- Most cheapest )
option 2 NEWLAND:EM3095(1D/2D barcode reader-- hardware decoding)
option 3 symbol:SE955(1D laser barcode reader)
option 4 Symbol: se4500(1D&2D barcode reader-- software decoding)
External Interface USB HOST/RS232(Customized)
Protection class IP65
Drop resistance level 1.5m
Camera Function YES 8MP Camera
Video Support still image and video capture
Sensor G-sensor LIS3DH
Compass AK09911C
Gyro MPU3050C
Light STK3410
Keypad Front 17
Side 4
Interface Mini-USB connector USB2.0 connection
SIM card slot *2
TF card slot Yes
power jack Yes
Audio Jack Yes
Battery Type rechargeable Li-ion battery 4500mAh
Standby Time 500hours
Calls Time Up to 6hours
Charging Time 4 hours
Physical Characteristics Dimension 175*76*27mm
Weight >400g with battery (according config)
Printer Module Specifications
Printing method Direct thermal line printing
Paper width 57mm
Print width 48mm
Resolution Ration 8 dots/mm (384 dots/line )
Life of printing head 5,000,000 -15,000,000 character lines
Printing speed 40-60mm/sec
Character size 8*16dots , 12*24dots
Paper supplied 57mm wide , 30mmø
Interface Serial RS232C/TTL
Operating temperature 0℃--50℃
Storage temperature -20℃ -- 60℃
Operating humidty 10%--80%
Storage humidty 10%--90%
Fingerprint Module Specifications
sensor TCS1
1:1 verification matching speed 50us per template
1:1000 Fingerprint search time < 1s
Resolutions 500DPI
Array Size 256x360 pixels
Security level 1-5, defaut value is 3, adjustable
Capacity 1000 fingerprints
FAR ＜0.001% (Security Level is 3)
FRR ＜0.005% (Security Level is 3)
Working current 55mA
Peak current 80mA
Communication interface UART TTL(RS232)/USB2.0
Communication Baud rate

9600bps,19200bps,38400bps,57600bps,115200bps(defaut),

230400,460800,921600
Working temperature -30℃~+70℃
Working humidity 20%-90%

Our Services

As a OEM/ODM and R&D manufacturer of PDA, we support you:

  • Completely Free SDK and technical support for you.
  • ODM/OEM and 6 kinds of customization services according to your needs.
  • 13months warranty for your devices and other parts. and 6 months for the batteries. Exend warranty,it'll cost 0.5% for each per year.
  • Free maintenance of the devices and part of accessories replacement in the warranty .if out of the warranty, you'll have to pay the basic cost for them.
Company Information

Beijing SPEEDATA is committed to provide advanced data acquisition terminal in each field. after long-term accumulation, we have built a comprehensive and professional technology team and service, has a wealth of experience in the field .whatever you need GIS ,Automatic identification technology or mobile devices , our highly technical conformity ability and professional service will provide the most suitable solution for you.

Company "Speedata" brand products sell well both domestic and abroad .we have many sales outlets in domestic market ,clients contains: Hanting hotel,bright dairy, unilever, hainan mobile, Qinghua Tongfang, logistics etc ; Overseas customers in USA,,Mexico,Italy , Egypt,Ukraine and other countries.

OEM Service

1.As a hardware PDA producer, We also offer OEM/ODM design and manufacturing service for hardware required for Data collector terminal PDA, including

  • Brand & Logo
  • Different colors
  • Multiple modules integration
  • Wide industrial and business solutions
  • Competitive and diverse price ranges

8 years' experience of R&D and OEM/ODM services for customers all over the world.

2.As for software integration , We not only support 18 kinds of multiple modules but also supply 3 compatible operating systems. Those Including

  • The most popular Android 4.4 and Windows CE or Mobile
  • 1D/2D barcode scanner
  • LF/HF/UHF RFID as well as NFC RFID Function.
  • Biometric fingerprint reader
  • Thermal printer
  • DGPS/ PSAM/ 433M/ IC Card/ MSR/ IR Meter Reading

Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS

Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPSAndroid Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPSAndroid Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
Packaging & Shipping

Android Handheld PDA biological fingerprint reader with Wifi Bluetooth GPRS GPS
