Specifications
Brand Name :
Speedata
Model Number :
TT45-C5M-M6-LF1
Certification :
ISO9001/CE/CQC/CCC
Place of Origin :
Beijing,China
MOQ :
1 unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5000pcs per month
Delivery Time :
3-7 working days
Packaging Details :
Independent packing with standard carton box, accessories(battery/charger/USB data cable/protection cover/hand strap)
OS :
Windows mobile 6.1/6.5 Windows CE 6.0
CPU :
TI3715 A8 1Ghz
Memory :
Flash ROM 512MB
Battery :
rechargeable Li-ion battery 4500mAh
Dimension :
175*76*27mm
Weight :
>400g with battery (according config)
Camera :
5MP
Description

Wireless Passive Tag LF Handheld Rfid Reader Portable 134.2Khz Windows OS

Wireless Passive Tag LF Handheld Rfid Reader Portable 134.2Khz Windows OS

Quick Details of LF reader:

1, Key feature: Basic functions as Smart phone.

2, Memory Capacity: 512MB ROM, 512MB RAM.

3, Wireless functions: WIFI, BLUETOOTH, GPS( support full AGPS).

4, Camera function: 5MP, support still image and video capture.

5, Wide range of purpose: Animal/container/tool identification; bus card,ID card,attendance card; library, goods tracking, inspection, medicine; vehicle management, asset management, high speed charge; logistics&express, retail, FMCG; print railway ticket, print bar/QR code; swipe passport/driving license/member card/magnetic card.

6, Powerful productivity to make sure the delivery time.

7, Free SDK and 13 months warranty, technical support.

Specifications of LF reader:

OS option
OS option 1 Windows mobile 6.1/6.5
option 2 WM CE 6
option 3 Android 4.0
Hardware
Core board
CPU TI3715 A8 1Ghz
WWLAN option 1 without modem
option 2 Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS 850/900/1900/ 2100MHz HSPA )
Phone call &SMS function NA. (Only supports Internet access.)
Memory Flash ROM 512MB
RAM 512MB DDR
Extend Slot Micro SD 32G (SDHC)
EMMC ROM OPTION 4GB ROM
Motherboard
Display 4.5inch IPS 854*480 (Without Transflective screen)
touch screen 4-wire resistive
Form Factor Bar type classical PDA,Industrial appearance
GPS UBLOX 6010
Bluetooth JORJIN WG7310 Bluetooth
WiFi JORJIN WG7310 WiFi (802.11 b/g/n)
External Interface USB HOST/RS232(Customized)
Protection class IP65
Drop resistance level 1.5m
Camera Function Camera 5MP Camera
Video Support still image and video capture
Keypad Front 17
Side 4
Interface Mini-USB connector USB2.0 connection
SIM card slot Yes
TF card slot Yes
power jack Yes
Audio Jack Yes
Battery Type rechargeable Li-ion battery 4500mAh
Standby Time 500hours
Calls Time Up to 6hours
Charging Time 4 hours
Physical Characteristics Dimension 175*76*27mm
Weight >400g with battery (according config)
Extensions
PSAM(Optional) ISO7816 (SIM card interfance)
MSR(Optional) Compatible with one, two, three track. (without PCI, EMV security certification.)
IC card reder(Optional) ISO7816 ID-1
Fingerprint reader option 1 UPEK TCS1 (meet the FBI’s FIPS-201)
option 2 UPEK TCS2SS
Printer(Optional) 2 inch Direct thermal line printing
Far Infrared Meter Reading (Optional) IEC62056-21(IEC1107) communication protocol
zigbee(Optional) 2.4Ghz
RFID option 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
option 2 LF RFID(125KHz)
option 3 HF RFID(13.56MHz ISO 1443A/B ISO 15693)
option 4 NFC(include 13.56MHz ISO 1443A/B )
option 5 UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 shipset
option 6 UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) with R2000 shipset

Product Use of LF reader:

1. Read animal tag of 134.2khz for animal recognition.

2. Container and Tool recognition.

3. Electronic lock anti-theft.

4. Data collector in many areas.

Advantages of LF reader:

1. R & D technology support

Our R & D team have around 28 software & hardware hightech engineers, 27% of the whole employees, who have professional background in Electrical Engineering.

Atthe same time, our chairman Mr shao and genernal manager Mr Wu have extensive experiences in hardware development and product management.

since its reasonable structure and professional ability , our products become more stable and compatible.

As expected, we have built up a strong spirit of collaboration teamwork and gained a good reputation from our customers.

2. Strong customized capabilities

Speedata serves wide industries and fields, such as the electric power, mapping, egovernment, logistics, traceability management, fixed asset management.etc. we have accumulated rich and extensive experiences in those industries.

we pay more attention to design personalized software and hardware products as well as whole solutions development.

The products will develop in the direction of the platformization and modularization and put technology into the public platform to simplify for its secondary development.

At the same time, we supply core board customization, sensors and module development to combine with platform quickly to meet customers demand.
