Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
Specifications
Brand Name :
SPEEDATA
Model Number :
KT55-N63
Certification :
CE, 3C,ISO9001, IP65
Place of Origin :
Beijing China
MOQ :
1pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000pcs/month
Delivery Time :
one week
Packaging Details :
one device in an individual carton box with standard accessory
Name :
2d barcode module trade
OS :
Android 5.1
CPU :
Octa-core 1.3GHz
ROM :
16GB
RAM :
2GB
Extensive Slot :
128GB
Main Screen :
5.5 inch OLED 1920*1080 FHD
Sub Screen :
0.91 OLED
Description

Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics

Pls directly send message to contact sales for more Information. Thannk you!

Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics

SPECIFICATION

KT55 Android Device
OSAndroid 5.1
CORE
CoreCPUOcta-core 1.3GHz
ARM® Cortex-A53
WWLANFDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8
Flash ROM16GB
RAM2GB DDR3
General Configuration
DisplayMain Screen5.5 inch OLED 1920*1080 FHD
Sub-screen0.91 OLED
Touch screenMulti-point touch capacitive screen
FingerprintYes
GPSSupport GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
Bluetoothv2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi2.4G+5GHZ 802.11 a/b/g/n
Protection classIP65
Drop resistance level1.5m
Camera (Yes)Rear camera13MP Camera
Front camera5MP Camera
KeypadFront /Side5 side buttons
InterfaceMicro-USB connectorUSB2.0 OTG
SIM card slot1 standard SIM slot
1 Micro SIM slot
TF card slotYes
power jackMicro-USB
Audio JackYes
External InterfaceOPTIONUSB, RS232, SPI, GPIO
BatteryTyperechargeable Li-ion battery 6000mAh
Standby Time600hours
Calls TimeUp to 6hours
Charging Time5 hours (USB charging)
Physical CharacteristicsDimension170*79*13mm
Weight>250g with battery (according config)
Operating temperature-20°C to 50°C / -4°F to 122°F
Storage temperature-30°C to 70°C / -22°F to 158°F
Humidity (non-condensed)Operating 10% to 90% / Storage 5% to 95%
Electrostatic discharge± 15 kV air discharge, ± 8 kV contact discharge
EMC regulationCE
OPTIONS
Appearance coloroptionvarious color options
Wireless chargingYesinclude Wireless transmitting base.
Far Infrared Meter ReadingoptionIEC62056-21(IEC1107) communication protocol
IRIS recognitionoptionThe recognition distance is less than 20cm
PSAMoptionISO7816 (SIM card interface)
NFCoptionNFC(Compatible 13.56MHz ISO 14443A ISO15693)
Barcode scannerYesHoneywell N6603 1D & 2D barcode scanner

Clip device
RFID readeroption 1LF RFID(134.2KHz, ISO11784/11785, FDX-B/HDX) - reading distance 10cm
option 2LF RFID(125KHz) - reading distance 10cm
option 3HF RFID(13.56MHz ISO 14443A/B ISO 15693)- reading distance 5cm
option 4R2000 UHF RFID 860-960MHz ISO18000-6C (EPC Gen2) - reading distance up to 3m-5m
IC card reader(Optional)optionISO7816 ID-1
Printeroption2 inch direct thermal printer
MRZoptionICAO Document 9303 / E13B and OCRB fonts
Fingerprint readeroption 1UPEK TCS1 (meet the FBI’s FIPS-201)
option 2UPEK TCS2SS
option 3Customized according to customer needs.
Free ExtensionMultiple extension interface, such as RS232, GPIO, USB, SPI. You can freely design what you want.


SPEEDATA SERVIDE

  • Free SDK Provide
  • Technical Support from Professional Engineer
  • 1 year warranty or extensive warranty


Rugged Handheld 2d Barcode Module Trade with Pistol for Warehouse Management Logistics
