Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC
Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC
Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC
Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC
Specifications
Brand Name :
speedata
Model Number :
TT35
Certification :
IP65 CE 3C
Place of Origin :
mainland china
MOQ :
10PCS
Payment Terms :
Western Union, T/T, L/C, D/A, D/P
Supply Ability :
100000per Month
Packaging Details :
gift box package
color :
black
Memory Capacity :
>256MB
Operating System :
windows CE/Mobile
Wifi :
yes
GPS :
yes
camera :
5MP
Description

Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC

Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC

SPEEDATA TT35 is a Rugged IP65 Mobile Handheld PDA device , High-performance and Strong ability of Integration ;

Key features:
* All in one, modular design, multifunctional extension, accept customized service;
* Support 1D/2D barcode scanning, LF/HF/UHF RFID/fingerprint reading, thermal printer, MSR, PSAM functions etc.
* With professional rugged design technology, withstand drop, IP65 Industrial Class;
* With three open operation systems, provide complete SDK and technical support, make further app development easily;
* 3.5” TFT LCD with resistive touch screen, sunlight visible.

Flexible customized-- Choose as you like :Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC

Support Android 4.0 OS, Windows mobile 6.1/6.5 OS, WinCE OS

Rugged IP65

SPEEDATA TT35 Rugged Handheld PDA can withstand multiple drops onto concrete from 1.5 meters.

IP65: Waterproof, dustproof and drop resistant. Suitable for all kinds of complicated industrial environment.

Windows Mobile Rugged Handheld RFID Reader IP65 LF HF UHF NFC

Data Sheet:
OS option
OS option 1 Windows mobile 6.1/6.5
option 2 WM CE 6
option 3 Android 4.0
Hardware
Core board
CPU TI3715 A8 1Ghz
WWLAN option 1 without modem
option 2 Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE UMTS 850/900/1900/ 2100MHz HSPA )
Memory Flash ROM 512MB
RAM 512MB DDR
Extend Slot Micro SD 32G (SDHC)
Motherboard
Display 3.5inch TFT LCD (Transflective screen VGA 640*480)
touch screen 4-wire resistive
Form Factor Bar type classical Pocket PC,Industrial appearance
GPS UBLOX 6010
Bluetooth JORJIN WG7310 Bluetooth
WiFi JORJIN WG7310 WiFi (802.11 b/g/n)
PSAM(Optional ) ISO7816 *2 (SIM card interfance)
MSR(Optional) Compatible with one, two, three track. (without PCI, EMV security certification.)
IC reader(Optional ) ISO7816 ID-1
Fingerprint reader(Optional ) SM-621B(Optical fingerprint)
Thermal Printer (Optional ) Direct thermal line printing(2inch thermal printer)
433MHz Wireless transmission(Optional) Require customers to provide 433Mhz wireless modules or specifications.
Far Infrared Meter Reading (Optional) IEC62056-21(IEC1107) communication protocol
RFID Reader option 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
option 2 LF RFID(125KHz)
option 3 HF RFID(13.56MHz ISO 1443A/B ISO 15693)
option 4 NFC Reader (only android OS)
option 5 2.4G RFID(Customer specified module, customized according to customer's module.)
option 6 UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 shipset
barcode scanner option 1 NEWLAND:EM1300(1D barcode reader--most cost effective scan engine)
option 2 NEWLAND:EM3000(1D/2D barcode reader--hardware decoding )
option 3 symbol:SE955(1D laser barcode reader)
option 4 HoneyWell:N4313 (1D laser barcode reader)
option 5 Symbol: se4500(1D&2D barcode reader--software decoding )
External Interface USB HOST/RS232(Customized)
Protection class IP65
Drop resistance level 1.5m
Camera Function option 5MP Camera
Video Support still image and video capture
Keypad Front 30keys
Side 4keys
Interface Mini-USB connector USB2.0 connection
SIM card slot Yes
TF card slot Yes
power jack Yes
Audio Jack Yes
Battery Type rechargeable Li-ion battery 4500mAh
Standby Time 500hours
Calls Time Up to 6hours
Charging Time 4 hours
Physical Characteristics Dimension 182*82*36mm
Weight >400g with battery (according config)
