4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz
4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz
4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz
4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz
Specifications
Brand Name :
SPEEDATA
Model Number :
KT45
Certification :
IP65 CE ROHS
Place of Origin :
China Mainland
MOQ :
1 lot
Payment Terms :
Western Union
Supply Ability :
10000per week of portable fingerprint scanner
Packaging Details :
Portable Fingerprint Scanner printer packing: 1pcs ,usb data cable:1pcs ,charger:1pcs,protection cover:1pcs,hand strap:1pcs
Item Name :
Portable Fingerprint Scanner
OS :
Android 4.4.2
CPU :
A7 1.3GHz
Memory :
8GB ROM
DISPLAY :
4.5INCH IPS LCD
STORAGE :
32GB
CAMERA :
8MP
BATTERY :
4500mAh 3.7V or 2250mAh 7.4V
CERTIFICATE :
3C FCC ROHS IP65 1.5M DROP
PRICE :
Cheap Price From Factory Direct
Wireless Communication :
Bluetooth WIFI GPRS GPS
Brand :
Speedata
Description

4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz

Multiple modulars of KT45 Portable Fingerprint Scanner printer

MSR(Optional) Compatible with one, two, three track. (without PCI, EMV security certification.)
PSAM(Optional) ISO7816 (SIM card interfance)

IC card reader

(Optional)

 ISO7816 ID-1
Fingerprint reader option 1 UPEK TCS1 (meet the FBI’s FIPS-201)
option 2 UPEK TCS2SS
printer (YES ) 2 inch Direct thermal line printing

Far Infrared Meter

Reading (Optional)

 IEC62056-21(IEC1107) communication protocol

433Mhz module

(Optional)

 Require customers to provide 433Mhz wireless modules or specifications.
zigbee (Optional) Require customers to provide 433Mhz wireless modules or specifications.
RFID Reader option 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) -- reading distance 10cm
option 2 LF RFID(125KHz) -- reading distance 10cm

option 3 HF RFID(13.56MHz ISO 14443A/B ISO 15693)

-- reading distance 5cm
option 4 NFC(include 13.56MHz ISO 14443A/B )

option 5 UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) /

ISO18000-6A,B compatibility in direct mode----with AS3992 shipset

-- reading distance up to 3m
barcode scanner option 1 NEWLAND:EM1300(1D barcode reader-- Most cheapest )
option 2 NEWLAND:EM3095(1D/2D barcode reader-- hardware decoding)
YES symbol:SE955(1D laser barcode reader)
option 4 Symbol: se4500(1D&2D barcode reader-- software decoding)

More details of KT45 Portable Fingerprint Scanner printer

Development Environment
Operating System Android 4.4.2
SDK Software Development Kit
Language Java
Fundamental Characteristics
CPU ARM® Cortex-A7 MPCoreTM (LPDDR2 and LPDDR3) Quad-core 1.3Ghz
Memory 1GB DDR3 RAM + 8GB Frash ROM
Storage Micro SD/TF card max.32GB expansion
Display 4.5-inch IPS 480 * 854 Multi-point touch capacitive screen
Communications
WWLAN GSM band 850/900/1800/1900MHz,
Class 12 GPRS,
EDGE UMTS 850/900/1900/2100MHz HSPA
WiFi 2.4Ghz 802.11 b/g/n
Bluetooth V2.1+EDR / 3.0+HS / V4.0 Low Energy(LE)
GPS Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
DGPS (please check options)
Physical Characteristics
Dimensions 175 * 76 * 28mm
Weight 400g (includes main battery)
Expansion Slots 1*PSAM, 2*SIM
Battery rechargeable li-ion battery 4500mAh 3.7V
Or rechargeable li-ion battery 2250mAh 7.4V (if with printer)
500hours standby time, Up to 6hours calling time, 4hours charging time
Camera 8MP Camera
Video Support still image and video capture
Audio 3.5mm 4way plug
Keypad Front 17keys, Side 4keys
Interfaces 1*MicroSD/TF, 1*Audio Jack, 1*Micro USB, 1*Power Jack
USB Host (Optional), RS-232 interface (Optional)
User Environment
Operating Temp. -10 to 50℃
Humidity 10%RH - 90%RH (Non-condensing)
Protection class IP65
Drop resistance level 1.5M

Specifications of KT45 Portable Fingerprint Scanner printer

1.4.5inch high-definition IPS LCD capacitive touch screen to meet your visual enjoyment

2.800MP camera with high definition ,it's easy to collect all kinds of image information

3.Support 1D/2D barcode scanning,LF/HF/UHF RFID/fingerprint reading, terminal printer, MSR, PSAM function etc.

4.Android 4.4 Operation System, More Stable and Reliable,provide complete SDK and technical support to make further app development easily

5.Special structure and external cushion protection design, solid and wearproof body shape

6.Matched with the machine seat charger, to ensure the charging interface durable,it's more quicker and easier

7.IP65 Industrial Class, 1.8M drop protection

8.Multiple Functions optional: card reader, printer, fingerprint, infrared reader, temperature, etc

More pictures of KT45 Portable Fingerprint Scanner printer

4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz

4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz

4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz

Factory of SPEEDATA of KT45 Portable Fingerprint Scanner printer

4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz

Industrial application Solutions of SPEEDATA Biometric Portable Fingerprint Scanner

4.5 Inch IPS LCD Biometric Fingerprint Scanner 8GB ROM A7 1.3GHz

Best portable fingerprint scanner with cost-effective price OEM/ODM from china factory direct
