Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection
Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection
Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection
Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection
Specifications
Brand Name :
Speedata
Model Number :
KT45Q
Certification :
IP65 ISO9001 FCC
Place of Origin :
Mainland china
MOQ :
1 set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
10000unit/ month
Packaging Details :
conventional packing-1pcs;usb data cable-1pcs;charger-1pcs;protection cover-1pcs;hand strap-1pcs.
Item :
UHF RFID Card Reader
CPU :
ARM@Cortex-A53 1.3GHz Qard-core
Memory :
1GB RAM
Display :
4.5inch screen
Camera :
8AF
Communication :
3G 4G
OS :
android5.1
Momory :
1GB RAM
Description

Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection

Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection

Selling points of KT45Q RFID Card Reader

  • Android 5.1
  • Support 3G 4G
  • 4.5inch high-definition IPS LCD capacitive touch screen to meet your visual enjoyment
  • 800MP camera with high definition ,it's easy to collect all kinds of image information
  • Support 1D/2D barcode scanning,LF/HF/UHF RFID, fingerprint reading, terminal printer, MSR, PSAMfunction etc.
  • Android 4.4 Operation System, More Stable and Reliable,provide complete SDK and technical support to make further app development easily
  • wearproof dustproof waterproof body shape
  • Matched with the machine seat charger, to ensure the charging interface durable,it's more quicker and easier
  • IP65 Industrial Class, 1.8M drop protection
  • Multiple Functions optional: card reader, printer, fingerprint, infrared reader, temperature, etc
  • 8 Years Manufacture professional R&D in Industrial PDArs with OEM/ODM services

Optional functions

OS Android 5.1 4G Wireless FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8
CPU ARM@Cortex-A53 1.3GHz Qard-core WWLAN

GSM/GPRS/EDGE:850/900/1800/

1900mMhz
UMTS/HSPA:850/900/1900/2100MHz
Memory 8GB ROM+1GB RAM Interface

1*MicroSD/TF, 1*Audio Jack, 1*Micro USB,

1*Power Jack
USB Host/RS-232 interface (Customized)
Display

4.5’’ IPS 480 * 854 LCD

Multi-point touch screen

 Camera

Support still image and video capture

AF 8MP

Positioning

module

 GPS/AGPS/Ublox8030 Battery 4500mAh/3.7V or 2250mAh/7.4V
Storage

Micro SD/TF card

max.32GB expansion

 Quality 3C /FCC /ROHS /IP65 /1.5M drop
Slot 1*PSAM, 2*SIM

Function

Options

 1.Barcode scanner:1D/2D
2.RFID reader:LF/HF/UHF/NFC
3.Fingerprint
4.DGPS/PSAM/433M/Printer
5.IC Card reader/MSR/IR Meter reading

More details of KT45Q RFID Card Reader

android OS
OS Android 5.1
Hardware
Core board CPU Quad-core 1.3Ghz
ARM® Cortex-A53 (LPDDR2 and LPDDR3)
WWLAN FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8
Flash ROM 8GB
RAM 1GB DDR3
Motherboard
Display @ 4.5inch IPS 480*854
touch screen Multi-point touch capacitive screen
Form Factor Bar type classical PDA,Industrial appearance
GPS

Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN).

Support Full AGPS
DGPS (please check options)
Bluetooth v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi 2.4Ghz 802.11 b/g/n
External Interface USB HOST/RS232(Customized)
Protection class IP65
Drop resistance level 1.5m
Camera Function Camera 8MP Camera
Video Support still image and video capture
Sensor G-sensor YES
Keypad Front 17
Side 4
Interface Mini-USB connector USB2.0 connection
SIM card slot *2
TF card slot Yes
power jack Yes
Audio Jack Yes
Battery Type rechargeable Li-ion battery 4500mAh
Standby Time 500hours
Calls Time Up to 6hours
Charging Time 4 hours
Physical Characteristics Dimension 175*76*27mm
Weight >400g with battery (according config)
OPTIONS
DGPS ublox LEA-6T (with RTK)
MSR(Optional)

Compatible with one, two, three track.

(without PCI, EMV security certification.)
PSAM(Optional) ISO7816 (SIM card interfance)
IC card reader(Optional) ISO7816 ID-1
Fingerprint reader option 1 UPEK TCS1 (meet the FBI’s FIPS-201)
option 2 UPEK TCS2SS
printer 2 inch Direct thermal line printing
Far Infrared Meter Reading (Optional) IEC62056-21(IEC1107) communication protocol
433Mhz module

Require customers to provide 433Mhz wireless

modules or specifications.
zigbee

Require customers to provide 433Mhz

wireless modules or

specifications.
RFID Reader option 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
option 2 LF RFID(125KHz)
option 3 HF RFID(13.56MHz ISO 1443A/B ISO 15693)
option 4 NFC(include 13.56MHz ISO 1443A/B )
option 5

UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) /

ISO18000-6A,B compatibility in direct mode-

---with AS3992 shipset
option 6

UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) /

ISO18000-6A,B compatibility in direct mode----

with R2000 shipset, Long distance reader.

option 7

UHF RFID 860-960MHZ ISO18000-6C (EPC

Gen2) -with PR92000 shipset
barcode scanner option 1 NEWLAND:EM1300(1D barcode reader)
option 2 NEWLAND:EM3000(1D/2D barcode reader)
option 3 Symbol:SE955(1D laser barcode reader)
option 4 HoneyWell:N4313 (1D laser barcode reader)
option 5 Symbol: SE4500(1D&2D barcode reader)

Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection

Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection

Pocket UHF Bluetooth Hand Held Rfid Reader 1.8m Drop Protection
