Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader
Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader
Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader
Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader
Specifications
Brand Name :
Speedata
Model Number :
KT45Q
Certification :
IP65 ISO9001 FCC
Place of Origin :
Mainland china
MOQ :
1 set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
10000unit/ month
Packaging Details :
conventional packing-1pcs;usb data cable-1pcs;charger-1pcs;protection cover-1pcs;hand strap-1pcs.
Item :
UHF RFID Reader Scanner
CPU :
ARM@Cortex-A53 1.3GHz Qard-core
Memory :
8GB ROM+1GB RAM
Display :
4.5inch screen
wireless :
3G Bluetooth GPRS
Camera :
8AF
Communication :
3G 4G
OS :
android5.1
Description

Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader

Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader

Advantages of KT45Q UHF RFID Reader Scanner

  • Universal product, Support extending corresponding module according to customers'demands
  • Suitable android 5.1 for different industries and solutions with variety of colors optional
  • The incubator and active tags are matched to create a complete cold-chain transport system
  • Support 3G 4G
  • 8 Years Manufacture professional R&D in Industrial PDArs with OEM/ODM services.

Optional functions of KT45Q UHF RFID Reader Scanner

android OS
OS Android 5.1
Hardware
Core board CPU Quad-core 1.3Ghz
ARM® Cortex-A53 (LPDDR2 and LPDDR3)
WWLAN FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8
Flash ROM 8GB
RAM 1GB DDR3
Motherboard
Display @ 4.5inch IPS 480*854
touch screen Multi-point touch capacitive screen
Form Factor Bar type classical PDA,Industrial appearance
GPS

Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN).

Support Full AGPS
DGPS (please check options)
Bluetooth v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi 2.4Ghz 802.11 b/g/n
External Interface USB HOST/RS232(Customized)
Protection class IP65
Drop resistance level 1.5m
Camera Function Camera 8MP Camera
Video Support still image and video capture
Sensor G-sensor YES
Keypad Front 17
Side 4
Interface Mini-USB connector USB2.0 connection
SIM card slot *2
TF card slot Yes
power jack Yes
Audio Jack Yes
Battery Type rechargeable Li-ion battery 4500mAh
Standby Time 500hours
Calls Time Up to 6hours
Charging Time 4 hours
Physical Characteristics Dimension 175*76*27mm
Weight >400g with battery (according config)
OPTIONS
DGPS ublox LEA-6T (with RTK)
MSR(Optional)

Compatible with one, two, three track.

(without PCI, EMV security certification.)
PSAM(Optional) ISO7816 (SIM card interfance)
IC card reader(Optional) ISO7816 ID-1
Fingerprint reader option 1 UPEK TCS1 (meet the FBI’s FIPS-201)
option 2 UPEK TCS2SS
printer 2 inch Direct thermal line printing
Far Infrared Meter Reading (Optional) IEC62056-21(IEC1107) communication protocol
433Mhz module

Require customers to provide 433Mhz wireless

modules or specifications.
zigbee

Require customers to provide 433Mhz wireless

modules or specifications.
RFID Reader option 1 LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
option 2 LF RFID(125KHz)
option 3 HF RFID(13.56MHz ISO 1443A/B ISO 15693)
option 4 NFC(include 13.56MHz ISO 1443A/B )
option 5

UHF RFID 860-960MHZ ISO18000-6C

(EPC Gen2) / ISO18000-6A,B compatibility in

direct mode----with AS3992 shipset
option 6

UHF RFID 860-960MHZ ISO18000-6C (

EPC Gen2) / ISO18000-6A,B compatibility i

n direct mode----with R2000 shipset, Long distance reader.

option 7

UHF RFID 860-960MHZ ISO18000-6C (EPC

Gen2) -with PR92000 shipset
barcode scanner option 1 NEWLAND:EM1300(1D barcode reader)
option 2 NEWLAND:EM3000(1D/2D barcode reader)
option 3 Symbol:SE955(1D laser barcode reader)
option 4 HoneyWell:N4313 (1D laser barcode reader)
option 5 Symbol: SE4500(1D&2D barcode reader)

Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader

Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader

Long Range Handheld RFID Reader Waterproof Wireless Rfid Mobile Reader
