23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT
23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT
23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT
23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT
23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT
23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT
Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CT6F-015
Place of Origin :
SHENZHEN
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
MOQ :
1000pcs
Packaging Details :
Color Box+Packing Box 42*42*22cm
Delivery Time :
15-45 Days
Payment Terms :
T/T
Supply Ability :
2000pcs/day
Conductor Size :
23 AWG
Category :
Cat6
Jacket Material :
LSZH
Color :
Red
Conductor Dimensions :
0.550±0.005mm
Cable Length :
1000ft
Cable Type :
FTP
Conductor Material :
Copper
Description

Cat6 FTP 23AWG Red LSZH Jacket Network Cable 1000Mbps High Speed 1000FT

Product Description:

1.The Cat6 FTP 23AWG Red LSZH (Low Smoke Zero Halogen) Jacket Cable is precisely engineered to meet CAT6 Ethernet Cable standards. It supports up to 1000Mbps Gigabit Ethernet speeds, ideal for businesses and homes in the digital age with high - demand applications like HD streaming and gaming. With 23 AWG conductor size, it resists interference and crosstalk well for reliable data transmission. As a low - smoke zero - halogen cable, it's safer in fires with minimal smoke and no halogen gases, suitable for safety - critical environments.


2.Its 305 - meter length is great for large - scale wiring in big homes and commercial buildings. It enables seamless connection of various devices like computers, smart TVs, and security systems across the building. The conductor dimension of 0.550±0.005 ensures wide device compatibility, simplifying integration with existing network infrastructure.


3.In summary, this cable combines high quality, reliability, and performance. It has copper conductor for conductivity, LSZH jacket for protection and fire - related safety, 23 AWG size for optimal performance, and 305 - meter length. It's the top choice for high - speed Ethernet networks, offering speed, reliability, and safety.

Technical Parameters:

Cable Type FTP
Category Networking Cables
Jacket Material LSZH
Conductor Material Copper
Conductor Size 23 AWG
Cable Length 305 Meters
Color Red
Conductor Dimensions 0.550±0.005mm

Product Description:

Cat6 FTP 23AWG Red LSZH Jacket Network Cable 1000Mbps High Speed 1000FT
Rev.: A ECN Description:
Construction Item Description Electrical Property

Conductor

Material

Bare Solid Copper(elongation:

19-24%)

 Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
OD 23 AWG Resistance unbalance within a pair ≤ 2%

Insulation

 Material

HDPE

 Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

>1500 MΩ / 100m
OD 1.15 ±0.01 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.25 mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m

Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω
2p: white + 2 orange stripes & orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min

No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown

insulation

 elongation before aging ≥ 300%

Pair Twist

Lay & Direction

 1p: S=19.0 mm (27%) tensile strength before aging ≥12 MPa
2p: S=23.5 mm (35%) elongation after aging ≥ 150 %
3p: S=21.5 mm (31%) tensile strength after aging ≥10.5 MPa
4p: S=27.0 mm (40%)

jacket

 elongation before aging ≥ 150 %
OD / tensile strength before aging ≥ 13.5 MPa

Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 125 %
Direction according to the drawing tensile strength after aging ≥ 12.5 MPa
Filler cross member 5.0X5.0X0.5mmT Packing
OD / Drum NA
Filler Ripcord 300D
Drain Wire Tinned Copper

Shield

 Shield Shield
Construction /
Material Polyester/Aluminium (PET/ALU)
Coverage ≥ 115%

Jacket

 Material LSZH, 60P, -20~75℃
Hardness 81± 3
OD 7.2 ± 0.2
Average THK 0.55 ~ 0.60

Color

Red
Marking Color

according to the customer's

requirements
Marking

according to the customer's

requirements

Electrical Properties
Conductor Resistance at 20°C NF EN 50289-1-2 / IEC 60189-1 ≤ 9.5 Ω / 100m
Resistance unbalance within a pair NF EN 50289-1-2/ IEC 60708 ≤ 5%

Dielectric Strength

Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min

NF EN 50289-1-3 / IEC 61196-1-105

No breakdown
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

NF EN 50289-1-4 / IEC 60885-1

 >1500 MΩ / 100m
Mutual capacitance NF EN 50289-1-5 /IEC 60189-1 5600pF / 100m MAX
Capacitance unbalance pair to ground at 800Hz or 1 kHz NF EN 50289-1-5 / IEC 60189-1 ≤ 160 pF / 100m
Characteristic impedance at 100MHz NF EN 50289-1-11/ IEC 61156-1 100 ± 15 Ω
Spark Test UL444 2000 ± 250VOC

Transmission Properties
CAT 6 ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013

No.

Frequency

Attenuation (Max)

 Propagation Delay (MAX) Propagation Delay Skew (MAX)

Return Loss (Min)

NEXT (Min)

PS NEXT (Min)

EL-FEXT (Min)

PS EL-FEXT (Min)
MHz dB/100m ns/100m ns/100m dB(on 100m) dB(on 100m) dB(on 100m) dB(on 100m) dB(on 100m)
1 4 3.78 552 45 23.01 66.27 63.27 55.96 52.96
2 8 5.32 546.73 45 24.52 61.75 58.75 49.94 46.94
3 10 5.95 545.38 45 25 60.3 57.3 48 45
4 16 7.55 543 45 25 57.24 54.24 43.92 40.92
5 20 8.47 542.05 45 25 55.78 52.78 41.98 38.98
6 25 9.51 541.2 45 24.32 54.33 51.33 40.04 37.04
7 31.25 10.67 540.44 45 23.64 52.88 49.88 38.1 35.1
8 50 13.66 539.09 45 22.21 49.82 46.82 34.02 31.02
9 62.5 15.38 538.55 45 21.54 48.36 45.36 32.08 29.08
10 100 19.8 537.6 45 20.11 45.3 42.3 28 25
11 125 22.36 537.22 45 19.43 43.85 40.85 26.06 23.06
12 200 28.98 536.55 45 18 40.78 37.78 21.98 18.98
13 250 32.85 536.28 45 17.32 39.33 36.33 20.04 17.04
14
15
16
17
18
Remarks: ＊ are the reference values.

Applications:

The Cat6 FTP 23AWG Red LSZH (Low Smoke Zero Halogen) Jacket Cable for Reliable Connectivity is perfect for applications where high - speed data transfer is essential. It is an ideal choice for businesses that require reliable and fast connections between their network devices. This Cat6 Ethernet Cable can be used in a wide range of scenarios as follows:


1.Offices - The Cat6 FTP 23AWG Red LSZH Jacket Cable is excellent for office use, where numerous devices need to be network - connected. It offers reliable and fast connections, guaranteeing efficient work for everyone in the office. Additionally, in case of any unforeseen incidents like a fire, its LSZH property ensures the safety of the environment by producing minimal smoke and no halogen gases.


2.Data Centers - This cable is highly suitable for data centers, where vast amounts of data are transferred between servers and other network devices. It is engineered to manage high - speed data transfer and can provide dependable connections for critical applications. The LSZH feature also adds an extra layer of safety within the data center environment.


3.Home Networks - The Cat6 FTP 23AWG Red LSZH Jacket Cable is also great for home networks. It can be used to connect gaming consoles, smart TVs, and other devices to the internet, ensuring fast and reliable connections. In a home setting, the low - smoke and zero - halogen properties provide peace of mind, especially considering the safety of family members.


4.Industrial Environments - The Cat6 FTP 23AWG Red LSZH Jacket Cable is designed to endure harsh industrial environments. It can be used in factories, warehouses, and other industrial settings where reliable connections are crucial. In these environments with potential fire hazards, the low - smoke zero - halogen design can prevent the release of harmful substances, protecting both equipment and workers.


5.Hospitals and Healthcare Facilities - In hospitals, where continuous and reliable network connections are essential for patient monitoring systems, medical equipment, and communication among staff, this cable's reliable performance and LSZH properties make it an ideal choice. In case of a fire emergency, the cable won't emit harmful halogen gases that could endanger patients or interfere with sensitive medical equipment.


6.Educational Institutions - Schools and universities with numerous computers, projectors, and other network - enabled devices can benefit from this cable. The high - speed data transfer capability ensures smooth online teaching and learning activities, and the LSZH feature adds to the safety of the educational environment.

23AWG FTP CAT6 Cable Red LSZH Network Cable 1000Mbps High Speed 1000FT

FAQ:

Q: What is the model number of this product?

A: The brand name of this product is ITI-LINK.

Q: What is the model number of this product?

A: The model number of this product is ITI-CT6F-015.

Q: Where is this product manufactured?

A: This product is manufactured in SHENZHEN.

Q: What type of cable is this?

A: This is an FTP CAT6 cable.

Q: What is the length of this cable?

A: The length of this cable may vary depending on the purchase, please check the product description for the length of the cable that you are interested in.
