24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT
24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT
24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT
24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT
24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT
24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT
Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CABLE-005
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin :
shenzhen
MOQ :
1000pcs
Packaging Details :
Color Box+Packing Box 36*36*21cm
Delivery Time :
15-45Days
Payment Terms :
T/T
Supply Ability :
2000pcs/day
Color :
GRAY
Data Transfer Rate :
100 Mbps
Length :
1000 ft
Application :
100Base-TX/100Base-T4/100VG-AnyLan/ATM
Conductor Size :
24 AWG
Certifications :
UL, ETL, RCM, CPR, CSA, CE, RoHS
Conductor aMaterial :
Bare Copper
Cable Type :
U/UTP
Jacket Material :
PVC
Flame retardant grade :
CM
Description

Cat5e UTP CM PVC Plenum Cable 24AWG Copper Gray High Speed Network Cable 1000FT

Quick Detail:

· Bare solid copper conductor

· 100MHz

· Jacket PVC, 60P, -20~75℃

· Rate temperature:60℃ ~75℃

· InstallationTemperature: -30℃-+50℃

· CompliestoANSI/TIA-568-B.2&IS0/EC11801

· CE, RoHS, TUV, UL compliant, CPR, ETL, RCM, ISO9001

Description:

1. This Cat5e Ethernet cable is made of high-quality raw materials and strictly follows international communication standards to ensure efficient and stable data transmission. Its unique CM flame retardant rating design means that the network cable performs well in combustion testing, effectively preventing the spread of fire and complying with safety regulations in commercial buildings. Whether in home networks, office cabling, or other situations that require high standard communication and data transmission, this Ethernet cable can provide excellent performance and reliable security.

2. Category 5e network cable support Ethernet transmission speeds of up to 100Mbps and have backward compatibility, allowing seamless connection with existing Ethernet devices. It uses four pairs of precision twisted copper core wires internally, effectively reducing signal interference and ensuring the integrity and accuracy of data during transmission.

3. At the same time, the network cable is covered with a durable PVC sheath, which not only enhances the durability of the cable, but also makes it easier to install and manage.

24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT

Product Description
❶ Inner Conductor Composition : Solid Bare Copper (BC)
Diameter : See table below
❷Insulation Composition : High density Polyethylene (HDPE)
Diameter : See table below
❸Filler Type of filler : Ripcord
Composition : Polyester

❹Jacket

 Composition : PVC, Rated 60 or 75℃
Dimensions : See table below
color : according to the the customer's requirements

Specifications:

Product Description: Cat 5e UTP 4 X 2 X 24AWG (CM)
Rev.: A ECN Description:
Construction Item Description Electrical Property

Conductor

Material

Bare Solid Copper(elongation:

19 ~ 24%)

 Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
OD 24 AWG Resistance unbalance within a pair ≤ 2%

Insulation

Material

HDPE 8303

 Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

>1500 MΩ / 100m
OD 0.90 ± 0.01 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.20 mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m

Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω

2p: white + 2 orange stripes &

orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min

No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown

insulation

 elongation before aging ≥ 300%

Pair Twist

Lay & Direction

 1p: S=20.0 mm (28%) tensile strength before aging ≥12 MPa
2p: S=17.5 mm (24%)) elongation after aging ≥ 150 %
3p: S=22.0 mm (32%) tensile strength after aging ≥10.5 MPa
4p: S=15.5 mm (21%)

jacket

 elongation before aging ≥ 150 %
OD / tensile strength before aging ≥ 13.5 MPa

Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 125 %
Direction according to the drawing tensile strength after aging ≥ 12.5 MPa
Filler / Packing
OD / Inner Box NA
Filler Material Ripcord Master Carton NA
Construction 300D

Outside Shield

 Shield /
Construction /
Material /
Coverage /

Jacket

 Material PVC, Rated 60 or 75℃
Hardness 81 ± 3
OD 5.0 ± 0.2
Average THK 0.45 ~ 0.55

Color

 GRAY

Marking Color

 BLACK
Marking according to the customer's requirements

Electrical Properties
Conductor Resistance at 20°C

UL 444 & CSA C22.2

No. 214

 ≤ 9.5 Ω / 100m
Resistance unbalance within a pair ≤ 2%

Dielectric Strength

Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min

No breakdown
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

>1500 MΩ / 100m
Mutual capacitance 5600pF / 100m MAX
Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m
Characteristic impedance at 100MHz 100 ± 15 Ω
Spark Test 2000 ± 250VOC

Transmission Properties
CAT5e U/UTP

No.

Frequency

Attenuation (Max)

Propagation Delay

(MAX)

Propagation Delay Skew

(MAX)

Return Loss (Min)

NEXT (Min)

PS NEXT (Min)

EL-FEXT (Min)

PS EL-FEXT (Min)
MHz dB/100m ns/100m ns/100m dB(on 100m) dB(on 100m) dB(on 100m) dB(on 100m) dB(on 100m)
1 4 4.05 552 45 23.01 56.27 53.27 51.96 48.96
2 8 5.77 546.73 45 24.52 51.75 48.75 45.94 42.94
3 10 6.47 545.38 45 25 50.3 47.3 44 41
4 16 8.25 543 45 25 47.24 44.24 39.92 36.92
5 20 9.27 542.05 45 25 45.78 42.78 37.98 34.98
6 25 10.42 541.2 45 24.32 44.33 41.33 36.04 33.04
7 31.25 11.72 540.44 45 23.64 42.88 39.88 34.1 31.1
8 50 15.07 539.09 45 22.21 39.82 36.82 30.02 27.02
9 62.5 16.99 538.55 45 21.54 38.36 35.36 28.08 25.08
10 100 21.98 537.6 45 20.11 35.3 32.3 24 21
11
12
13
14
Remarks: ＊ are the reference values

Notices:

1. Open the packaging, check the products carefully, and take them gently.

2. Please strictly follow the wiring standards during construction, and do not tie or excessively bend the network cables.

3. When making RJ45 network cable connectors, please follow the T568B or T568A standards to ensure the correct wire sequence and avoid problems such as disconnected lines or unstable network connections.

4.It is best to use a single network cable at a distance of no more than 100 meters to ensure optimal transmission performance.

5. Ensure that the shielded network cable is grounded during installation.

Applications:

1. CM flame-retardant grade Cat5e Ethernet cable are widely used in various situations that require secure and efficient network communication due to their excellent flame-retardant performance and stable data transmission capabilities. This network cable plays a crucial role in indoor cabling systems in residential, office, school, hospital, and commercial buildings. It not only supports fast Ethernet transmission of up to 100Mbps, ensuring smooth transmission of high-definition videos, large files, and other data, but also, due to its CM flame retardant rating, can effectively slow down the spread of fire, reduce the production of smoke and toxic gases, and win valuable time for personnel evacuation and fire rescue in the event of an unexpected fire.

2. Especially in public buildings with extremely strict fire safety requirements, such as libraries, data centers, laboratories, etc., CM flame-retardant grade Category 5e network cables are indispensable. It can not only meet the demand for high-speed data transmission, but also ensure the continuous and stable operation of network communication systems in emergency situations, providing solid support for emergency response and command dispatch. In addition, its easy installation and low maintenance costs make this network cable the preferred solution for indoor network cabling projects.

24AWG Cat5e UTP CM PVC Plenum Cable Copper Gray High Speed Ethernet Cable 1000FT

FAQ

UL/CE/RoHS/ETL/CPR Certificate Lan cable Cat5e U/UTP 24AWG Extend To 350MHz​ CM PVC Bare Solid Copper

Q1. Can I order samples of Lan cables?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A: We need 3-5 days to complete the sampling, and 15-45 days for mass production before shipping.

Q3. Do you have a minimum order quantity limit for network cable orders?

A: The minimum order quantity for our order is 1000PCS, but it will also depend on the total quantity of the products. The minimum order quantity for different products can vary.

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by sea, which usually takes about 7 days to arrive.

Q5. How to proceed an order for network cable?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6.Is it OK to print my logo on network cable product?

A: Yes. Please inform us formally before our production.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 10 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, for individual defective products, we will remedy them as soon as possible and send them to you, or we can discuss solutions based on the actual situation to achieve 100% satisfaction for you.
