LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable
LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable
LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable
LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable
LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable
LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable
Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CT5U-002
Place of Origin :
shenzhen
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
MOQ :
1000pcs
Payment Terms :
T/T
Supply Ability :
2000pcs/day
Delivery Time :
15-45Days
Packaging Details :
Color Box+Packing Box 36*36*21cm
Frequency :
100 MHz
Termination Type :
TIA/EIA 568B
Color :
Green
Conductor Material :
Copper
Certifications :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Conductor Size :
24 AWG
Length :
1000 Feet
Jacket Material :
LSZH
Description

Cat5e UTP 100MHz LSZH 24AWG 1000ft Green High Spped Network Cable

Product Description:

1.The cable features a TIA/EIA 568B termination type, which ensures that it is compatible with a wide range of devices and networks. This makes it easy to install and use, even for those who are not technically savvy. The cable is also UL Listed and ETL Verified, which means that it has been tested and certified to meet industry standards for safety and performance.

2.The UTP CAT5E Cable is constructed from high-quality materials, including a LSZH jacket and copper conductor. Low-smoke and halogen-free cables have the characteristics of producing less smoke when burning, not releasing toxic gases such as hydrogen halide, being of high safety, and possessing good electrical properties and flame retardancy.The copper conductor ensures that data is transmitted quickly and reliably, with minimal interference.

3.This cable has a frequency rating of 100 MHz, which means that it can support high-speed data transfer rates of up to 1 Gbps. This makes it suitable for use in demanding applications such as video streaming, online gaming, and large file transfers.

4.Overall, the UTP CAT5E Cable is an excellent choice for anyone who needs a reliable and high-quality Ethernet patch cable. Whether you are setting up a new network or upgrading an existing one, this cable is sure to provide the performance and reliability that you need. So why wait? Order your Cat5E Ethernet Patch Cable today and start enjoying faster, more reliable network connections!

Features:

  • Product Name: UTP CAT5E CABLE
  • Length: 1000 Feet
  • Conductor Size: 24 AWG
  • Termination Type: TIA/EIA 568B
  • Certifications: UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
  • Conductor Material: Copper
  • Suitable for: Cat5e SFTP Cable, Cat5e SFTP Cable, CAT6A CAT7 CAT8 Cable

Technical Parameters:

Certifications UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Jacket Material LSZH
Conductor Size 24 AWG
Frequency 100 MHz
Color Green
Length 1000 Feet
Conductor Material Copper
Termination Type TIA/EIA 568B

Product Description: Cat 5e U/UTP 4 X 2 X 24AWG LSZH
Rev.: A ECN Description:
Construction Item Description Electrical Property

Conductor

Material

Bare Solid Copper(elongation:

19 ~ 24%)

 Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
OD 24 AWG Resistance unbalance within a pair ≤ 2%

Insulation

Material

HDPE 8303

 Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

>1500 MΩ / 100m
OD 0.90 ± 0.01 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.20 mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m

Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω
2p: white + 2 orange stripes & orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min

No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown

insulation

 elongation before aging ≥ 300%

Pair Twist

Lay & Direction

 1p: S=20.0 mm (28%) tensile strength before aging ≥12 MPa
2p: S=17.5 mm (24%)) elongation after aging ≥ 150 %
3p: S=22.0 mm (32%) tensile strength after aging ≥10.5 MPa
4p: S=15.5 mm (21%)

jacket

 elongation before aging ≥ 150 %
OD / tensile strength before aging ≥ 13.5 MPa

Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 125 %
Direction according to the drawing tensile strength after aging ≥ 12.5 MPa
Filler / Packing
OD / Inner Box NA
Filler Material Ripcord Master Carton NA
Construction 300D

Outside Shield

 Shield /
Construction /
Material /
Coverage /

Jacket

 Material LSZH, 60P, -20~75℃
Hardness 81 ± 3
OD 4.8 ± 0.15
Average THK 0.30 ~ 0.40

Color

 Green
Marking Color black
Marking

according to the customer's

requirements

Electrical Properties
Conductor Resistance at 20°C NF EN 50289-1-2 / IEC 60189-1 ≤ 9.5 Ω / 100m
Resistance unbalance within a pair NF EN 50289-1-2/ IEC 60708 ≤ 2%

Dielectric Strength

Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min

NF EN 50289-1-3 / IEC 61196-1-105

No breakdown
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

NF EN 50289-1-4 / IEC 60885-1

>1500 MΩ / 100m
Mutual capacitance NF EN 50289-1-5 /IEC 60189-1 5600pF / 100m MAX
Capacitance unbalance pair to ground at 800Hz or 1 kHz NF EN 50289-1-5 / IEC 60189-1 ≤ 160 pF / 100m
Characteristic impedance at 100MHz NF EN 50289-1-11/ IEC 61156-1 100 ± 15 Ω
Spark Test UL444 2000 ± 250VOC

Transmission Properties
CAT5e ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013

No.

Frequency

Attenuation (Max)

Propagation Delay

(MAX)

Propagation Delay Skew

(MAX)

Return Loss (Min)

NEXT (Min)

PS NEXT (Min)

EL-FEXT (Min)

PS EL-FEXT (Min)
MHz dB/100m ns/100m ns/100m dB(on 100m) dB(on 100m) dB(on 100m) dB(on 100m) dB(on 100m)
1 4 4.05 552 45 23.01 56.27 53.27 51.96 48.96
2 8 5.77 546.73 45 24.52 51.75 48.75 45.94 42.94
3 10 6.47 545.38 45 25 50.3 47.3 44 41
4 16 8.25 543 45 25 47.24 44.24 39.92 36.92
5 20 9.27 542.05 45 25 45.78 42.78 37.98 34.98
6 25 10.42 541.2 45 24.32 44.33 41.33 36.04 33.04
7 31.25 11.72 540.44 45 23.64 42.88 39.88 34.1 31.1
8 50 15.07 539.09 45 22.21 39.82 36.82 30.02 27.02
9 62.5 16.99 538.55 45 21.54 38.36 35.36 28.08 25.08
10 100 21.98 537.6 45 20.11 35.3 32.3 24 21
11
12
13
14
Remarks: ＊ are the reference values

Applications:

1.The ITI-CT5U-002 UTP CAT5E CABLE is jacketed with LSZH.It is ideal for indoor use and can withstand exposure to harsh environmental conditions. The cable is TIA/EIA 568B compliant, ensuring that it is compatible with most networking equipment and devices.

2.The ITI-CT5U-002 UTP CAT5E CABLE comes in a length of 1000 feet and is colored green, making it easy to identify and manage. It is suitable for a wide range of applications, including home networks, office networks, data centers, and server rooms.

3.This product is a cost-effective solution for those who need a reliable and high-quality Ethernet patch cable. It is an excellent alternative to CAT6A, CAT7, and CAT8 cables, providing fast and reliable network connectivity at a lower cost.

The ITI-CT5U-002 UTP CAT5E CABLE can be used in various scenarios, including:

  • Connecting computers, printers, and other devices to a network
  • Connecting switches, hubs, and routers to a network
  • Connecting servers and storage devices to a network
  • Connecting IP cameras and other surveillance equipment to a network
  • Connecting VoIP phones and other communication devices to a network

In conclusion, if you are looking for a reliable and cost-effective Ethernet patch cable, the ITI-LINK ITI-CT5U-002 UTP CAT5E CABLE is an excellent choice. It is suitable for various application occasions and scenarios and provides fast and reliable network connectivity. It is an excellent alternative to CAT6A, CAT7, and CAT8 cables, making it an affordable solution for your networking needs.

LSZH UTP 100MHz 24 AWG Cat 5e Cable 1000ft Green High Sped Network Cable

Packing and Shipping:

Product Packaging:

The UTP CAT5E CABLE product is packaged in a sturdy cardboard box to ensure safe delivery. The box measures 36 cm in length, 36cm inches in width, and 21cm in height.

Shipping:

Our standard shipping time is 15-45 days. We offer free shipping within the United States. For international shipping, additional fees may apply. We ship via USPS, UPS, or FedEx depending on the destination and weight of the package. Once the package is shipped, we will provide a tracking number for your convenience.

FAQ:

Q: What is the brand name of this UTP CAT5E cable?

A: The brand name is ITI-LINK.

Q: What is the model number of this UTP CAT5E cable?

A: The model number is ITI-CT5U-002.

Q: Where is this UTP CAT5E cable manufactured?

A: This cable is made in SHENZHEN.

Q: What is the maximum transmission speed of this UTP CAT5E cable?

A: This UTP CAT5E cable can transmit data at speeds up to 1000Mbps (Gigabit Ethernet).

Q: Can this UTP CAT5E cable be used for outdoor installations?

A: No, this UTP CAT5E cable is not suitable for outdoor installations as it is not designed to withstand exposure to harsh weather conditions.
