Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine
Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine
Specifications
Brand Name :
automation JAGUAR
Model Number :
JAGUAR f400
Certification :
CE
Place of Origin :
shenzhen
MOQ :
1
Price :
USD 40000SET
Payment Terms :
T/T, Western Union
Supply Ability :
100SET/MONTH
Delivery Time :
25DAYS
Packaging Details :
vacuum packing
Plate Type :
Screen Printer
Condition :
New
Place of origin :
Guangdong, China
Gross Power :
50W
Warranty :
1 Year
Voltage :
380V
Usage :
Tube Printer
Repeat :
±0.01mm
Description

Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine

Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine

Specification

Items: Jaguar F850 Parameter
Repeat Position Accuracy ±0.01mm
Printing Accuracy ±0.025mm(Absolute Guarantees)
Cycle Time <11s (Excluding Printing & Cleaning)
Products Changeover <5Min
Screen Stencil Size/Min 737mm*737mm(Note: Cleaning Adhesive tape shall be replaced for 737mm stencil)
Screen Stencil Size/Max 1100mm*900mm
Screen Stencil Thickness 20mm ~ 40mm
PCB Size/Min 100*80mm
PCB Size/Max 850*500mm
PCB Thickness 0.8~6mm
PCB Warpage Ratio <1%(Based on diagonal length)
Bottom of Board Size 13mm(standard configuration), 25mm(optional configuration)
Edge of Board Size 3mm
Transport Height 900±40mm
Transport Direction Left-Right; Right-Left; Left-Left; Right-Right
Transport Speed 100-1500mm/sec Programmable
Board Location Support System Magnetic pin/ Side support block/ Flexible automatic pin(optional)
Clamping System Elastic side clamping/Vacuum nozzle/Elastic Z-direction tabletting(optional)
Print head Programmable integrated motor driven and pneumatic control print head
Squeegee Speed 10~200mm/sec
Squeegee Pressure 0~0.5MPa with adjustable pressure reducing meter valve
Squeegee Angle 60°(Standard)/ 55°/ 45°
Squeegee Type Steel squeegee (standard), rubber squeegee, customizable other types of squeegee.
Stencil Separation Speed 0.1~20mm/sec Programmable
Cleaning Methods Dry-type, wet-type, vacuum-type (Programmable combination of Cleaning methods)
Table Adjustment Range X: ±4mm;Y:±6mm;θ:±2°
Type of Image Fiducial Mark Standard geometry shape of fiducial mark, bonding pad / stencil hole
Camera System Single digital camera with upward/downward vision system
Air Pressure 4~6Kg/cm2
Air Consumption Approx 0.07m3 /min
Control Method PC Control
Power Supply AC:220±10%,50/60HZ 1Φ 1.5KW
Machine Dimensions 1740mm(W)*1560mm(D) *1510(H)mm (excluding the height of indicating lighthouse)
Weight Approx:1300Kg
Operation Temperature -20°C ~ +45°C
Operation Humidity 30%~60%

Packaging & Shipping

Packaging Details: Wooden Case for Reflow Soldering Oven
Delivery Detail: Shipped in 10 days after payment

Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine

our factory

Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine

Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine

our certificate

Touch Screen Automatic heat transfer printing machine/Solder Paste Printer/Pcb Screen Printing Machine

Nicole

Shenzhen Jaguar Automation Equipment Co., Ltd
TEL:+86-755-23316315
FAX:+86-755-29497125
MOBILE/WECHAT:+8613235536784

E-mail: Nicole@jaguar-ele.com

Skype:smtnicole11
ADD:Building B,FuDa Industrial Zone,National Highway 107,Shajing Town,Bao'an District,Shenzhen
