R8 Hot Air Reflow Soldeirng Equipment for Mobile Phone Assembly
R8 Hot Air Reflow Soldeirng Equipment for Mobile Phone Assembly
Specifications
Brand Name :
jaguar automation
Model Number :
R8
Certification :
CE
Place of Origin :
shenzhen
MOQ :
1
Price :
USD17000SET
Payment Terms :
T/T, Western Union
Supply Ability :
100SET/MONTH
Delivery Time :
25days
Packaging Details :
VACUUM PACKING AND WOODEN PACKING
Model :
JAGUAR R8/R8-N
Outside dimension :
5200 x 1400 x 1600mm
Standard color :
Computer grey
Weight :
2200kg
Number of heating zones :
Up8/bottm8
Length of heating zones :
3000mm
Warming time :
Approx. 20minutes
Temp. setting range :
Room temp-300 degree
Control system :
PLC+ Computer
Max. width of PCB :
450mm
PCB transmission agent :
chain +mesh
Conveyor height :
900± 20mm
Description
Product Description

R8 Hot Air Reflow Soldeirng Equipment for Mobile Phone Assembly

Specification:

R8 Hot Air Reflow Soldeirng Equipment for Mobile Phone Assembly

Model JAGUAR R8/R8-N
Outside dimension 5200 x 1400 x 1600mm
Standard color Computer grey
Weight 2200kg
Number of heating zones Up8/bottm8
Length of heating zones 3000mm
Number of cooling zones 2
Exhaust volume 10M³/min*2 exhausts
Power supply 5line, 3phase, 380V 50/60Hz
Start-up power 60KW
Power for warm up 50KW
Normal power 9KW
Heating pattern Up & Bottom Hot air
Warming time Approx. 20minutes
Temp. setting range Room temp-300 degree
Control system PLC+ Computer
Temperature control method PID close loop control +SSR driving
Temperature control precision ± 1.0degree
Temperature deviation on PCB ± 1-2 degree
Data storage Process data and status storage (80GB)
Abnormal alarm Abnormal temperature (extra-high/extra-low temp.)
Board dropped alarm Tower light: yellow warming: Green-normal: Red-abnormal
Max. width of PCB 450mm
Rail Number 1 Lane Or 2 Lane (option)
Components clearance Top/bottom clearance of PCB is 25mm
Conveyor height Light → right(option: R→ L)
PCB transmission agent chain +mesh
Conveyor height 900± 20mm
Conveyor speed range 0~2000mm/min

Packaging & Shipping

Mahcines are delivered in polywood case with vacuum package.
