PS 4-JAW SCROLL CHUCKS
PS 4-JAW SCROLL CHUCKS
Specifications
Brand Name :
NTH
Model Number :
PS-07,PS-09,PS-12,PS-16,
Place of Origin :
CHINA
MOQ :
1 set
Payment Terms :
T/T, Western Union
Delivery Time :
3 work days
Packaging Details :
Good and firm package is suitable for sea and air shipping
Price :
Negotiation
Product name :
PS 4-JAW SCROLL CHUCKS
Material :
Cast steel
Usage :
fixture/Gripping
Feature :
High precision/Stable/High quality
Size :
Refer to the specification
Service :
ODM/OEM is accpetable
Description

PS 4-JAW SCROLL CHUCKS

PS 4-JAW SCROLL CHUCKS

Specification UNIT:mm

MODEL/SPEC Max. RPM O.D.Clamping Range
mm		 I.D.Clamping Range
mm		 Weight
kg
PS-07 2000 Ø4-Ø180 Ø56-Ø170 12.1
PS-09 2000 Ø5-Ø220 Ø62-Ø210 19.4
PS-12 1800 Ø10-Ø300 Ø86-Ø290 38.1
PS-16 1500 Ø14-Ø400 Ø100-Ø380

82.4

MODEL/SPEC A B C D E F G H J K L
PS-07 193 76 155 172 58 5 3-M10×1.5P 75 22 28 11
PS-09 233 84 190 210 70 5.5 3-M12×1.75P 85 24 34.5 12
PS-12 310 96 260 285 105 7 3-M12×1.75P 110 30 45 14
PS-16 405 122 345 375 160 8 6-M14×2P 146 40 56 15

Subject to technology changes without prior information
Non-standard requirements can be made
