KD 3 jaw strong scroll chuck D1 camlock direct mounting 2 piece jaws
KD 3 jaw strong scroll chuck D1 camlock direct mounting 2 piece jaws
Specifications
Brand Name :
NTH Cooperated Brand
Model Number :
KD4-6",KD4-8",KD5-8",KD6-8",KD6-10",KD6-12",KD8-10",KD8-12",
Place of Origin :
CHINA
MOQ :
1 set
Payment Terms :
T/T, Western Union
Delivery Time :
3 work days available
Packaging Details :
Good and firm package is suitable for sea and air shipping
Price :
Negotiation
Certification :
CE
Product name :
3 jaw strong scroll chuck D1 camlock direct mounting 2 piece jaws
Material :
Cast steel
Usage :
fixture/Gripping
Feature :
High precision/Stable/High quality
Size :
Refer to the specification
Service :
ODM/OEM is accpetable
Description

3 jaw strong scroll chuck D1 camlock direct mounting 2 piece jaws

Gripping accuracy of 0.03mm (0.0012 inch) T.I.R..
Standard accessories chuck wrench, hex. key. and a set of mounting bolts. (UNC-bolts)
The body is made of MEEHANITE. It is suitably used for high speed revolution and 3 times more durable than regular material.

KD 3 jaw strong scroll chuck D1 camlock direct mounting 2 piece jaws

UNIT : mm

SPEC
Model		 Spindle
Size		 A B E H J K L Mounting
Dimensions
F1 / F2 / F3 / F4
KD4-6" D1-4 165 72 46 72 26 39 9 63.513 / 13 / 15.8 / 82.55
KD4-8" D1-4 200 77.2 53 82 28 42.2 11.5 63.513 / 13 / 15.8 / 82.55
KD5-8" D1-5 200 77.2 55 82 28 42.2 11.5 82.563 / 16 / 19 / 104.78
KD6-8" D1-6 200 77.2 58 82 28 42.2 11.5 106.375 / 17 / 22.2 / 133.35
KD6-10" D1-6 250 86 76 90.9 32 50.8 19.5 106.375 / 17 / 22.2 / 133.35
KD6-12" D1-6 306 107.5 103 114.5 40 57.8 21 106.375 / 13.5 / 22.2 / 133.35
KD8-10" D1-8 250 86 80 90.9 32 50.8 19.5 139.719 / 19 / 25.4 / 171.45
KD8-12" D1-8 306 107.5 103 114.5 40 57.8 21 139.719 / 18 / 25.4 / 171.45

SPEC
Model		 Allowable
Handle
Torque
(kgf‧m)		 Gripping
Force
(kgf)		 Max.
Speed
(r.p.m.)		 Weight
(kg)		 Moment
Of Inertia
I
(kg‧m2)		 Gripping Range
O.D. Range
I.D. Range
KD4-6" 9 2200 2000 11 0.04 Ø8-Ø160 / Ø55-Ø150
KD4-8" 11.5 2500 2000 18.5 0.07 Ø8-Ø180 / Ø62-Ø170
KD5-8" 11.5 2500 2000 18 0.07 Ø8-Ø180 / Ø62-Ø170
KD6-8" 11.5 2500 2000 17 0.07 Ø8-Ø180 / Ø62-Ø170
KD6-10" 19.5 4000 1800 29.5 0.2 Ø11-Ø220 / Ø70-Ø210
KD6-12" 21 4200 1800 47 0.5 Ø15-Ø300 / Ø90-Ø290
KD8-10" 19.5 4000 1800 27 0.2 Ø11-Ø220 / Ø70-Ø210
KD8-12" 21 4200 1800 47 0.5 Ø15-Ø300 / Ø90-Ø290
