LL-A Push Type Collet Chuck With Taper For Direct Mounting On Spindle Nose
LL-A Push Type Collet Chuck With Taper For Direct Mounting On Spindle Nose
LL-A Push Type Collet Chuck With Taper For Direct Mounting On Spindle Nose
LL-A Push Type Collet Chuck With Taper For Direct Mounting On Spindle Nose
Specifications
Brand Name :
NTH
Model Number :
LL-30A4,LL-36A5,LL-42A5,LL-42A6,LL-52A6,LL-60A6,LL-65A6,LL-80A8
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
1000 sets/M
Delivery Time :
3 work days available
Packaging Details :
Good and firm package is suitable for sea and air shipping
Product name :
PUSH TYPE COLLET CHUCK WITH TAPER FOR DIRECT MOUNTING ON SPINDLE NOSE
Material :
Cast steel
Usage :
Gripping/Fixture
Feature :
High precision/High quality
Size :
Refer to the specification
Service :
OEM/ODM is acceptable
Description

Product Details

Brand:NTH

It‵s a push type collet chuck, suitable for turning machine, CNC, or other tools machines.
Construction of high rigidity and high clamping accuracy and high rotary speed.

Taper connection model, it can be installed onto the related spindle nose directly.
The connecting spec is same as other "Through-hole power chuck", No need to change the "Draw tube".
It goes with the DIN 6343 standard collet.

Production Catalogue Download:LL-A SERIES.pdf

LL-A Push Type Collet Chuck With Taper For Direct Mounting On Spindle Nose

(unit: mm)

Spec/Model Plunger stroke
mm		 Grip Round Grip Hex. Grip Sq. Max.D.B.Pull
kgf		 Max clamping force
kgf
LL-30 A4 5 3~30 4~27 4~22 19.6(2000) 42.1(4300)
LL-36 A5 6 3~37 6~32 6~26 22.5(2300) 48.5(4950)
LL-42 A5 7 3~42 6~36 6~28 24.5(2500) 52.9(5400)
LL-42 A6 7 3~42 6~36 6~28 24.5(2500) 52.9(5400)
LL-52 A6 7 5~52 8~45 7~36 27.4(2800) 59.0(6020)
LL-60 A6 7 5~60 8~50 7~40 29.4(3000) 63.7(6500)
LL-65 A6 7 5~67 8~58 7~47 29.4(3000) 63.7(6500)
LL-80 A8 7 20~80 18~69 15~56 34.3(3500) 71.5(7300)

Spec/Model Max RPM Inertia moment
kg*m2		 Weight
kg		 Matched
Collet		 Matched cylinders Max Pressure
Mpa(kgf/cm2)
LL-30 A4 8000 0.038 4.1 163E H-1036 2.9(29)
LL-36 A5 6000 0.058 6.3 171E H-1246 2.5(25)
LL-42 A5 6000 0.057 6.1 173E H-1246 2.9(29)
LL-42 A6 6000 0.061 7.5 173E H-1246 2.9(29)
LL-52 A6 6000 0.093 13.8 177E H-1552 2.3(23)
LL-60 A6 5000 0.091 13.5 185E H-1875 1.8(18)
LL-65 A6 5000 0.104 14.5 185E H-1875 1.8(18)
LL-80 A8 4000 0.12 19.8 193E H-2091 1.6(16)

Spec/Model A B C D E F G H

J

Max

 K N P T
LL-30 A4 110 103.5 85 30 82.55 63.515 M55x1.5 45 M40x1.5 15 21.7 3~M10×30 2.3
LL-36 A5 135 130 100 27 104.78 82.563 M66x1.5 60 M55x2.0 17.5 30.9 4~M10×30 3.1
LL-42 A5 135 127 100 27 104.78 82.563 M66x1.5 60 M55x2.0 25 30.9 4~M10×30 3.1
LL-42 A6 165 127 100 32 133.35 106.375 M66x1.5 66 M60x2.0 22 30.9 4~M12×30 3.1
LL-52 A6 170 144 130 27 133.35 106.375 M90x1.5 66.7 M60x2.0 30 29.9 4~M12×35 3.1
LL-60 A6 170 145 130 27 133.35 106.375 M90x1.5 80 M74x2.0 30 29.9. 4~M12×35 3.1
LL-65 A6 210 135 136 27 133.35 106.375 M95x1.5 81 M75x2.0 20 29.9 4~M16×40 3.1
LL-80 A8 210 170 136 35 171.45 139.719 M114x2.0 99 M90x2.0 27.5 32.4 6~M16×40 3.1

Note: Subject to technology changes without prior information;

Non-standard requirements can be made.
